2022 America Hot Sell AWS Standard Civil Engineer Use Ultrasonic Weld Testing Equipment
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
2022 Canada Hot Sell Construnction Laboratory Use Ultrasonic Weld Testing Equipment
-
High precision China factory Digital Portable NDT ultrasonic flaw detector for sale
-
R800 Integrated Concrete Internal Scanner Rebar Locator Detector Concrete Coverage Meter
-
R800 Integrated Concrete Rebar Detector Detects The Thickness And Diameter Of The Protective Layer
-
Measuring instrument for positioning and protecting steel bars inside concrete
-
Integrated concrete scanner rebar locator | detector concrete cover meter
Product Description
Our Advantages
Product Description
Ultrasonic flaw detector can quickly, non-destructively and accurately detect various defects (cracks, inclusions, blowhole, etc.) inside the workpiece. It is widely used in aerospace, railway transportation, building steel structure, boiler pressure vessel and other fields. It is a necessary professional precision instrument for defect detection, quality control, in-service safety monitoring and life evaluation in railway, shipbuilding, metallurgy, chemical industry, petroleum and other industries.
Specification
Unique in design
Easy to operate
Durable
Product specifications: Multifunctional ndt instruments ultrasonic flaw detector for sale
Xxamination range: (0~9999)mm
working frequency: (0.2~20)MHz
Sound speed range: (1000~15000) m/s
Dynamic Range: ≥36dB
Vertical linearity error: ≤2.5%
Horizontal linearity error: ≤0.1%
Discrimination: >40dB(5P14)
Sensitivity margin: >65dB (deep 200mm 2 flat bottom hole)
Digital suppression: (0~80)%, does not affect linearity and gain
Electrical noise level: ≤8%
Probe type: Straight probe, oblique probe, dual crystal probe, penetration probe
Gate: Incoming gate, loss gate; single gate reading, double gate reading
Pulse amplitude: Low (300V), medium (500V), high (700V) grading options
Pulse Width: Continuous adjustment in the range of (0.1~0.5)μs to match probes of different frequencies
Probe damping: 100Ω, 200Ω, 400Ω optional
Real-time sampling of hardware: High resolution 10-bit AD converter with sampling speed of 160MHz and high waveform fidelity
Detection method: Positive half wave, negative half wave, full wave, radio frequency detection
Filter band: (0.2~20)MHz, fully automatic matching according to probe frequency, no need to set manually
Data storage: 100 sets of flaw detection parameter channels, 1000 flaw detection echo signals and parameters
Communication Interface: USB2.0 high speed communication transmission interface
Power supply: DC (DC) 9V; lithium battery works continuously for more than 8 hours
Dimensions: 263*170*61 (mm)
Ambient temperature and humidity: Temperature: (-10~50) °C Humidity: (20~95)%RH
Transaction process
Why Choose Us
Iwin testing equipment company is a high-tech enterprise focusing on the research and development, production and sales of engineering quality test and testing instruments.The company serves in the construction, the railroad, the highway, the water conservancy, the electric power, the university and the scientific research institute.To provide quality products, services and solutions for the industry. And establish a good long-term cooperative relationship with it.
"Build a craftsman's spirit and build a century-old enterprise" is the development concept we have been pursuing.
Product packaging
Our logistics
FAQ
1. who are we?
Iwin testing equipment based in Hebei, China, start from 2010.
Iwin testing equipment based in Hebei, China, start from 2010.
Sell to Domestic Market(50.00%),South America(15.00%),Southeast Asia(10.00%),Mid East(10.00%),North America(5.00%),Africa(5.00%),Western Europe(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
We are professional manufacturer. Before shipping ,we test machine for three times to ensure client receive excellent machine.
3.what machines can you buy from us?
4. why should you buy from us not from other suppliers?
We mainly develop high-technology, high quality, energy saving and environmental-friendly building material products . We produce products according to international standard specification, we also can offer OEM service , like many kinds of couplers .
5. what services can we provide?
Delivery Terms: FOB,CFR,CIF,EXW,FAS,Express Delivery,DAF；
Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese, German, Arabic, French.
2. how can we guarantee quality?
We are professional manufacturer. Before shipping ,we test machine for three times to ensure client receive excellent machine.
3.what machines can you buy from us?
Metal test, Pile test, Soil test, Asphalt test, Concrete test, Cement test.
4. why should you buy from us not from other suppliers?
We mainly develop high-technology, high quality, energy saving and environmental-friendly building material products . We produce products according to international standard specification, we also can offer OEM service , like many kinds of couplers .
5. what services can we provide?
Delivery Terms: FOB,CFR,CIF,EXW,FAS,Express Delivery,DAF；
Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese, German, Arabic, French.
