ABB PFCL201C 20KN 3BSE027070R20 Tensiometer PFCL201C20KN

ABB PFCL201C 20KN 3BSE027070R20 Tensiometer PFCL201C20KN

Contact US

Email: 3005304301@qq.com                                                                       Mobile: +86 18050025541

 Whatsapp/ Wechat/Skype: 18050025541                                                  Sales Manager: Linda

ABB PFCL201C 20KN 3BSE027070R20 Tensiometer PFCL201C20KN

Tension measuring instrument is divided into IP20 and IP65 two kinds of protection level, according to the installation environment for selection, model: PFEL111 PFEL112 PFEL113.

PFEL111: without DP interface, able to connect 2 pressure heads

PFEL112: with DP interface, able to connect 2 pressure heads

PFEL113: with DP interface, can be connected to 4 pressure head

1, Model: PFEA111

Description: Conventional control unit, capable of connecting 2 pressure heads, with IP20 and IP65 protection levels depending on the application environment, with PLC interface signal of 0--10V DC, various calibration and range parameters can be set on site.

　　2、Model：PFCL201C

　　Description: Pillow block type tension meter vertical pressure measuring element, using cylindrical plug connection; measuring force range: 5~50KN;

　　3、Model：PFCL201CD/CE

　　Description: Pillow block tension meter vertical pressure measuring element, using cable sealing connector / fixed cable connection with protective hose; measuring force range: 5~50KN;

　　4、Model：PFTL101A

　　Description: Pillow block type tension meter horizontal pressure measuring element, cylindrical plug connection, measuring force range: 0.2~2KN.

　　5、Model：PFTL101AE

　　Description: Pillow block type tension meter horizontal pressure measuring element, fixed cable connection, measuring force range: 0.2~2KN.

　　6、Model：PFTL101AER

　　Description: Acid-resistant pillow block tension meter horizontal pressure measuring element, fixed cable connection, force measuring range: 0.2~2KN. Used for paper wet end tension measurement, protection grade up to IP66/67

　　7、Model：PFTL101B

　　Description: pillow block tension meter horizontal pressure measuring element, cylindrical plug connection, measuring force range: 2~20KN.

　　8、Model：PFTL101BE

　　Description: Pillow block type tension meter horizontal pressure measuring element, fixed cable connection, measuring force range: 2~20KN.

　　9、Model：PFTL101BER

　　Description: Acid-resistant pillow block tension meter horizontal pressure measuring element, fixed cable connection, force measuring range: 2~20KN. Used for paper wet end tension measurement, protection grade up to IP66/67

　　10、Model：PFTL201C

　　Description: Pillow block tension meter horizontal pressure measuring element, cylindrical plug connection, measuring force range: 10~50KN.

　　11、Model：PFCL301E

　　Description: Mini type paper web tension vertical pressure measuring element, measuring range: 0.2~1KN

　　12、Model：PFTL301E

　　Description：Mini type paper web tension horizontal pressure measuring element, pressure measuring range: 0.1~1KN

　　13、Model：PFRL101D

　　Description: Radial pressure measuring element, rated load 5.0KN.

　　14、Model：PFRL101C

　　Description: radial pressure measuring element, rated load 0.5~2.0KN.

　　15、Model：PFRL101B

　　Description: Radial pressure measuring element, rated load 1.0KN.

　　16、Model：PFRL101A

　　Description: Radial pressure measuring element, rated load 0.5KN.

　　17、Model：PFEA113

　　Description: Tension controller, with four pressure measuring elements, Profibus-DP fieldbus communication function, six configurable analog output ports.

　　18、Model：PFEA112

　　Description: Add Profibus-DP fieldbus communication function on the basis of PFEA 111.

　　19、Model：PFEA111

　　Description: Tension controller, with two pressure measuring elements, compact and rail-mounted.

　　20、Model：PFTL201CE

　　Description: Pillow block type tension meter horizontal pressure measuring element, fixed cable connection, force measuring range: 10~50KN.

　　21、Model：PFTL201D

　　Description: Pillow block type tension meter horizontal pressure measuring element, cylindrical plug connection, measuring force range: 50~100KN.

　　22、Model：PFTL201DE

　　Description: Pillow block type tension meter horizontal pressure measuring element, fixed cable connection, measuring force range: 50~100KN.

　　23、Model：PFVL141V

　　Description: Rectangular measuring element, measuring force range: 0.63~56MN; width range: 70~610mm; length range: 120~1320mm height: 74mm.

　　24、Model：PFVL141C

　　Description: Circular pressure measuring element PFVL 141C, force measuring range: 1.6~60MN; diameter range: 210~890mm; height: 74mm.

　　25、Model：PFVL141R

　　Description: Toroidal pressure measuring element PFVL 141R, force range: 2~28MN; outer diameter range: 240~895mm; inner diameter range: 100~595mm height: 74mm

　　26、Model：PXAH401

　　Description: Millmate OperatUnit 400, panel mounted, can communicate with control unit network. Size: 160×235 ×?60 mm, front protection class IP65, other directions IP20, weight: 1.3 kg.

　　27、Model：PFVA401

　　Description: Rolling force controller, can provide excitation to the pressure measuring element, with analog input/output, digital input/output, Ethernet interface, RS232/485 interface, optional high-speed fieldbus communication interface.

　　28、Model：PFBL141B/C

　　Description: Vertical force test unit, divided into single/dual rollers, fixed/rotary shaft end different types, measuring range 4 - 400 kN. where the PFBL 141C form factor can be customized according to user requirements.

　　29、Model：PFEA101

　　Description：Constant tension closed loop control during unwind and winding, can be connected to pressure measuring elements and torque output devices such as brakes, clutches and motors.
