Help CenterALLOSUN EM480C Milliohm Meter LCD 200momh -20K in 6 Position Accurate Wide Measurement Range Resistance Meter
Related Products
-
Allosun EM480A Insulation Resistance Tester Portable Voltage AC 600V Professional Tester Resistance Continuity TesterNegotiableMOQ: 1 -
All-sun EM415 Telephone Network Phone Cable Wire Tracker Phone Generator Tester Diagnose Tone Networking ToolsNegotiableMOQ: 1
-
All-sun EM4212 Phase Sequence and Motor Rotation Tester, Motor Turn Direction CheckerNegotiableMOQ: 1
-
ALLOSUN UR4180 Ultrasonic Jewelry Cleaner for Diamonds, Rings, Necklaces, Watches, Eyeglasses, Sunglasses, Jewelry, DenturesNegotiableMOQ: 1
-
Allosun EM5812 Cable Length Meter Digital Cable Resistance Tester 30KM/100000ft Wire Cable Length Tester MeterNegotiableMOQ: 1
PEODUCTION DESCRIBTION
SPECIFICATION >>>
Range: 200m/2/20/200/2k/20kΩ
Resolution: 0.1m/1m/10m/0.1/1/10Ω
Testing current: 100/100/10/10/1/0.1mA
Power Supply: AC 110V/220V ±10%, 50/60HZ
FEATURES >>>
1.Low impendance measurement by four wires
2.Applicable measurement in resistance, motor coil, transformer, printed
circuit board.
3.Accurate measurement on conductor, welding point, etc.
4.Wide measurement range: 0.1mΩ to 20kΩ in 6 grades.
5.Hold switch: lockup reading on LCD display
GENERAL SPECIFICATION >>>
1. Display: 3 1/2 digits, LCD display with max. reading 1999 with decimal
point and measurement unit.
2. Overload indication: “1” indication
3. Zero adjust: external zero adjust knob.
4. Reading speed: about 2.5 times/ sec
5. Operating attitude: max. 2000m above level.
6. Operating ambience: indoor use, under environmental pollution grade two.
7. Operating temperature and R.H. value: 5-40 ℃, <75% RH.
8. Storage temperature and R.H. value: -10-60 ℃, <85%RH.
9. Power supply: AC 110V ±10%, 50/60HZ, or AC 220V ±10%, 50/60HZ
10.Power dissipation: ≤ 2A
11.Fuse specification:F 20A L 250V, Φ 5mm x 20mm
12.Dimensions: 168(L)X110(W)X62(D)mm
13.Weight: approx. 550g
Q: Are you factory manufacturer or trading company?
A: We are manufacturer, our factory--Eastern Intelligent Meter established on 1993, focus on test and inspection instrument. We have a better price than trading company.
Q:What is your MOQ?
A:The MOQ is 1 for products which we have in stock. If you need make customize, print your logo, please contact us for MOQ, because different product have different MOQ.
Q: How can I get your price for bulk order?
A:Please feel free to contact us on trademanager online or send us an inquiry, then we can discuss the detail.
Q: Can I print my logo on product and packing?
A: Yes,we have the neutral and our brand product in stock,if you need make customize,please contact us for the detail.
Q:What are the terms of payments you offer?
A:For small orders, we prefer pay by credit card and make deal by Trade Assurance. VISA and Mastercard are all OK.For bulk order,TT is a good choice.
Q:What is your lead time?
A:For product which we have in stock, we can send out in 1 working day. But it take time from our factory to shipping agent, the tracking number may update 3-5 days after we send out.
