SGMAH-02B1A21 200W Flange Mount Industrial Yaskawa SGMAH Series
US$ 1 - 1000000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
Yaskawa
Place of Origin:
Japan
Model Number:
SGMAH-02B1A21
Payment & Shipping
Payment Methods:
Port of Shipment:
Bao'an international airport
Delivery Detail:
4 days
Related Products
-
SGM-08A316S 750w Motor Industrial Import Yaskawa Ac Servo ModuleUS$ 1 - 1000000MOQ: 1 Unit -
SGMAH-02AAF4C Japan Yaskawa Servo Motor 200w Power Supply VoltageUS$ 1 - 1000000MOQ: 1 Unit
-
Easy To Maintain SGD7S-2R8A00A002 Yaskawa 3 Phase Servo Motor DriverUS$ 1 - 1000000MOQ: 1 Unit
-
SGM-04AW14BM Yaskawa SGM Series Moudel Two Phase AC Servo MotorUS$ 1 - 1000000MOQ: 1 Unit
-
SGM-04AWH26B Yaskawa Controller Moudel InsB Model Servo MotorUS$ 1 - 1000000MOQ: 1 Unit
Brand Name
Yaskawa
Place of Origin
Japan
Model Number
SGMAH-02B1A21
Type
Servo Motor
Certification
CE
Usage
Other, universal
Construction
Permanent Magnet
Efficiency
IE 3
Protect Feature
Explosion-proof
Voltage(V)
100V
Output Power
200V
Continuous Current(A)
3.1A
Speed(RPM)
3000R/MIN
Commutation
Brushless
| Brand: | Yasakawa | Model: | SGMAH-02B1A21 |
|---|---|---|---|
| Palce Of Origin: | Japan | Type: | Servo Motor |
| Supply Voltage: | 200W | Current: | 2.1A |
| Ins: | B | R/min: | 3000 |
| High Light: | ac servo motor,electric servo motor | ||
What Effect Does Gain Have on Performance?
The higher the gain, the less error (E) required to break friction or maintain velocity. The error required to
break friction will affect position accuracy at the end of a move, which makes it a major factor in
achieving repeatability. The error to break static friction can be measured with the loop closed by slowly
changing the command (C) by its least increment while observing the buildup of the error (E). As noted
earlier, a velocity loop will have a major impact on the error required to break friction. This test should be
done at several points along the travel since mechanical variations will cause the breakaway friction to
change.
The higher the gain, the less error (E) required to break friction or maintain velocity. The error required to
break friction will affect position accuracy at the end of a move, which makes it a major factor in
achieving repeatability. The error to break static friction can be measured with the loop closed by slowly
changing the command (C) by its least increment while observing the buildup of the error (E). As noted
earlier, a velocity loop will have a major impact on the error required to break friction. This test should be
done at several points along the travel since mechanical variations will cause the breakaway friction to
change.
Another common problem is null hunt, a phenomenon in which an axis moves back and forth with a
square waveform at a low frequency. This is usually caused by the breakaway or static friction being
significantly higher than the running friction. Essentially, the error builds up to break friction, but once
motion starts the error is more than necessary to maintain the desired velocity so it overshoots the desired
position. This continues to repeat in both directions. It can be prevented by lowering the gain, however
lowering the gain will also affect accuracy. Lowering the ratio of static to running friction can be
achieved with roller bearings or, as is more common now, through the use of a special coating material as
one of the bearing surfaces. A static to running ratio of 1.01 or less is achievable in this manner.
Accuracy during motion is a concern in many applications. Cutting metal, routing wood, etching glass,
and grinding silicon wafer edges are examples where extreme accuracy during motion is required. A
servo with a gain of 1 IPM/MIL will have 0.001" of error when traveling at 1 IPM, 0.01" at 10 IPM and
0.1" at 100 IPM. It follows that the best accuracy can be achieved by keeping velocities low and gain
high. This is a good generality, but not always that simple to achieve.
Configuration of Servo System
The following diagram illustrates a servo system in detail:
(1) Controlled system: Mechanical system for which the position or speed is to be controlled.This includes a drive system that transmits torque from a servomotor.
(2) Servomotor: A main actuator that moves a controlled system. Two types aravailable: AC servomotor and DC servomotor.
(3) Detector: A position or speed detector. Normally, an encoder mounted ona motor is used as a position detector.
(4) Servo amplifier: An amplifier that processes an error signal to correct the difference between a reference and feedback data and operates theservomotor accordingly. A servo amplifier consists of a
comparator, which processes error signals, and a power amplifier,which operates the servomotor.
(5) Host controller: A device that controls a servo amplifier by specifying a positionor speed as a set point.
Servo components (1) to (5) are outlined below:
(1) Controlled system
In the previous figure, the controlled system is a movable table for which the positionor speed is controlled. The movable table is driven by a ball screw and is connected tothe servomotor via gears.
So, the drive system consists of:
Gears + Ball Screw
This drive system is most commonly used because the power transmission ratio(gear ratio) can be freely set to ensure high positioning accuracy. However, play in thegears must be minimized.
The following drive system is also possible when the controlled system is a movable
table:
table:
Coupling + Ball Screw
When the power transmission ratio is 1 :1, a coupling is useful because it has noplay.
When the power transmission ratio is 1 :1, a coupling is useful because it has noplay.
This drive system is widely used for machining tools.
To develop an excellent servo system, it is important to select a rigid drive system that has no play. Configure the controlled system by using an appropriate drive system for the control purpose.
