Products Introduction
plastic conveyor roller
China manufacturer wholesale plastic belt conveyor roller buy from china
VIRT PLASTIC Ultra-high molecular weight polyethylene (UHMWPE) belt conveyor roller is a high-tech product, which consists of uhmwpe pipe,metal bearing, metal shaft , plastic bearing housing , sealing ring and so on . Compared with metal roller , uhmwpe plastic roller has many obvious advantages in performance.
China manufacturer wholesale plastic belt conveyor roller Plastic conveyor roller buy from china | ||||||
SN | Item | Unit | Index | |||
1 | Radial circular run-out | mm | ≤0.50 | |||
2 | Axial drifting | mm | ≤0.70 | |||
3 | Rotation resistance | N | ≤2.50 | |||
4 | After-falling off axial displacement | mm | ≤1.50 | |||
5 | After-falling off rotation resistance | N | ≤3.75 | |||
You can see the product display visually
Real shows
Pay attention to its details
.
Main Application
This product is widely used in the original dock transporting places where dust is bigger and the environment has high corrosive , such as mining , power , steel , stone materials factory , cement and coking plant , coal washing factory , salt plant , alkali plant , fertilizer factory , dock and so on .
UHMWPE Conveyor Roller Specification (Unit:mm)
Specification （mm） | Length （customize） | Bearing （HRB，LYC, FAG, SKF） | Pipe wall’s thickness （customize） |
Φ63 | 150--2000 | 6103 | 10 |
Φ89 | 150—2000 | 6204 | 11 |
Φ102 | 150—2000 | 6204/6205 | 11 |
Φ108 | 150—2000 | 6304/6205 | 11 |
Φ114 | 150—2000 | 6205 | 11 |
Φ127 | 150—2000 | 6204/6305/6306 | 11 |
Φ133 | 150—2000 | 6305 | 13 |
Φ140 | 150—2000 | 6305 | 13 |
Φ152 | 150—2000 | 6307 | 14 |
Φ159 | 150—2000 | 6307 | 14 |
TIPS DURING OPERATION
1.Prevent the sharp objects from scoring roller surface
2.Should not be used in the temperature greater than 80 degrees
3.Shall not use to destroy the structure and cause the loose firm ware.
Packaging | ||
Size | 150 (L) * 130 (W) * 120 (H) | |
Weight | 1.2 T | |
Packaging Details | The normal package is plywooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
