100% recycle virgin ptfe skived film
PTFE Molded sheet is manufactured by suspend PTFE resin after molding. It has the best ability to anti chemistry corrosion, and non-aging, and can be used under -180C ~ +260C without load, and it has the lowest fiction coefficients in known solid materials.
Skived PTFE Sheet, Virgin white Ptfe Sheet of advantages
- Unaffected by almost all chemical
- Continuous use at high temperatures
- Slippery non-stick surface
- Outstanding dielectric properties
- Outstanding chemical resistance
- Superb electrical insulating properties
- A wide working temperature range from -180 °C + 260°C
- A very low coefficient of friction, resulting in unique non-stick behaviour
- High dielectric properties
- Non-toxic
Virgin White PTFE Sheet, plastic skived ptfe sheet of properties
- Excellent chemical resistance
- Lowest co-efficient of friction
- Highest operating temperature and stability
- Physiologically inert
- Excellent electrical properties
Virgin PTFE Sheets, plastic ptfe sheets of size
Item |
Style |
Thickness |
Width |
Length |
|
PTFE Sheet (Teflon Sheet)
|
Skived |
0.1 mm ~ 10 mm |
1000mm, 1200mm, 1500mm |
1000mm ~ 10,000mm |
Molded |
2 mm ~ 100 mm |
300mm, 600mm, 900mm,1000mm,1200mm |
300mm, 600mm, 900mm,1000mm,1200mm |
|
Filled |
1mm ~100 mm |
1000mm, 1200mm, 1500mm |
1000mm ~10,000mm |
100% virgin PTFE sheet, ptfe sheet products of technology datas
Properties |
Unit |
Result |
Apparent density |
g/cm3 |
2.10~2.30 |
Tensile strength(min) |
Mpa |
≥25 |
Uitimate elongation(min) |
% |
≥200 |
Working Temp |
°C |
-180~260 |
Melting point |
°C |
327 |
Produce Max. Temp |
°C |
385 |
Hardness Rockwell |
|
M65 |
Dielectric Strength |
KV/mm |
59 |
Surface Resistivity |
Ohms |
>10^7 |
Flammability UL94 |
|
530 |
Delivery terms
1: Express Delivery
1) Advantage: Fast (3~6Days), door-to-door, wide-area coverage
2) Volume&weight restricted
3) Advices: Good for samll cargo
2: Sea transportation
1) Advantage: The cheapest, volume unlimited
2) Diavantage: long sailing time(15~30days), influenced by climate and port conditions
3) Advices: Bulk cargo, loose time
3: Air transportation
1) Fast(4~5days) , simple packing
2) The most expensive, volume restricted
3) For valuable cargo, urgent need
