Home > Products > Fiber Transceiver Module > 1000base-sx Sfp 1.25g MM 850nm 550m SFP Module
1000base-sx Sfp 1.25g MM 850nm 550m SFP Module
- T/T Credit Card
You May Like
Product Description
1000base-sx sfp 1.25G SR 850nm 550m sfp module
Description
1.The 1000base-sx sfp transceiver are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 0-120km transmission distance with SMF.
2.The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
3.The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
Main Features
1.Dual data-rate of 1.25Gbps/1.063Gbps operation
2.1310nm FP laser and PIN photodetector for 2-120km transmission
3.Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
4.Digital Diagnostic Monitoring: Internal Calibrationor External Calibration
5.Compatible with SONET OC-24-LR-1
6.Compatible with RoHS
Applications
Gigabit Ethernet
Fiber Channel
Switch to Switch interface
Switched backplane applications
Router/Server interface
Other optical transmission systems
Product List
| SFP (155M/622M/1.25G/2.125G/2.5G/4.25G) without DDMI | |||||||
| RSFP-0385M-02 | 155M | 850 | MM | 2KM | SFP | 0~70 | 850nm VCSEL |
| RSFP-0331M-02 | 155M | 1310 | MM | 2KM | SFP | 0~70 | FP(LED)+PIN |
| RSFP-0331S-L2 | 155M | 1310 | SM | 20KM | SFP | 0~70 | FP+PIN |
| RSFP-0331S-L4 | 155M | 1310 | SM | 40KM | SFP | 0~70 | FP+PIN |
| RSFP-0355S-L8 | 155M | 1550 | SM | 80KM | SFP | 0-70 | DFB+PIN |
| RSFP-1231S-L2 | 622M | 1310 | SM | 20KM | SFP | 0~70 | FP+PIN |
| RSFP-1231S-L4 | 622M | 1310 | SM | 40KM | SFP | 0~70 | DFB+PIN |
| RSFP-1255S-L6 | 622M | 1550 | SM | 60KM | SFP | 0~70 | DFB+PIN |
| RSFP-1255S-L8 | 622M | 1550 | SM | 80KM | SFP | 0~70 | DFB+PIN |
| RSFP-2485M-S5 | 1.25G | 850 | MM | 550M | SFP | 0~70 | VSCEL+PIN |
| RSFP-2431S-L2 | 1.25G | 1310 | SM | 20KM | SFP | 0~70 | FP+PIN |
| RSFP-2431S-L4 | 1.25G | 1310 | SM | 40KM | SFP | 0~70 | DFB+PIN |
| RSFP-2455S-L6 | 1.25G | 1550 | SM | 60KM | SFP | 0~70 | DFB+PIN |
| RSFP-2455S-L8 | 1.25G | 1550 | SM | 80KM | SFP | 0~70 | DFB+PIN |
| RSFP-2455S-12 | 1.25G | 1550 | SM | 120KM | SFP | 0~70 | DFB+APD |
| RSFP-4885M-S3 | 2.125G/2.5G | 850 | MM | 300M | SFP | 0~70 | VSCEL+PIN |
| RSFP-4831S-02 | 2.125G/2.5G | 1310 | SM | 2KM | SFP | 0~70 | FP+PIN |
| RSFP-4831S-L2 | 2.125G/2.5G | 1310 | SM | 20KM | SFP | 0~70 | DFB+PIN |
| RSFP-4855S-L6 | 2.125G/2.5G | 1550 | SM | 60KM | SFP | 0~70 | DFB+APD |
| RSFP-4855S-L8 | 2.125G/2.5G | 1550 | SM | 80KM | SFP | 0~70 | DFB+APD |
| SFP (155M/1.25G/2.125G/2.5G/4.25G) with DDMI | |||||||
| RSFP-0385M-02D | 155M | 850 | MM | 2KM | SFP | 0~70 | 850nm VCSEL |
| RSFP-0331M-02D | 155M | 1310 | MM | 2KM | SFP | 0~70 | FP(LED)+PIN |
| RSFP-0331S-L1D | 155M | 1310 | SM | 10KM | SFP | 0~70 | FP+PIN |
| RSFP-0331S-L4D | 155M | 1310 | SM | 40KM | SFP | 0~70 | FP+PIN |
| RSFP-0355S-L8D | 155M | 1550 | SM | 80KM | SFP | 0-70 | DFB+PIN |
| RSFP-1231S-L2D | 622M | 1310 | SM | 20KM | SFP | 0~70 | FP+PIN |
| RSFP-1231S-L4D | 622M | 1310 | SM | 40KM | SFP | 0~70 | DFB+PIN |
| RSFP-2485M-S5D | 1.25G | 850 | MM | 550M | SFP | 0~70 | VSCEL+PIN |
| RSFP-2431S-L2D | 1.25G | 1310 | SM | 20KM | SFP | 0~70 | FP+PIN |
| RSFP-2431S-L4D | 1.25G | 1310 | SM | 40KM | SFP | 0~70 | DFB+PIN |
| RSFP-2455S-L6D | 1.25G | 1550 | SM | 60KM | SFP | 0~70 | DFB+PIN |
| RSFP-2455S-L8D | 1.25G | 1550 | SM | 80KM | SFP | 0~70 | DFB+PIN |
| RSFP-2455S-12D | 1.25G | 1550 | SM | 120KM | SFP | 0~70 | DFB+APD |
| RSFP-4885M-S3D | 2.125G/2.5G | 850 | MM | 300M | SFP | 0~70 | VSCEL+PIN |
| RSFP-4831S-02D | 2.125G/2.5G | 1310 | SM | 2KM | SFP | 0~70 | FP+PIN |
| RSFP-4831S-L2D | 2.125G/2.5G | 1310 | SM | 20KM | SFP | 0~70 | DFB+PIN |
| RSFP-4831S-L4D | 2.125G/2.5G | 1310 | SM | 40KM | SFP | 0~70 | DFB+APD |
| RSFP-4855S-L6D | 2.125G/2.5G | 1550 | SM | 60KM | SFP | 0~70 | DFB+APD |
| RSFP-4855S-L8D | 2.125G/2.5G | 1550 | SM | 80KM | SFP | 0~70 | DFB+APD |
| RSFP-4855-12D | 2.125G/2.5G | 1550 | SM | 120KM | SFP | 0~70 | DFB+APD |
| RSFP-4G85M-S5D | 4.25G | 850 | MM | 500M | SFP | 0~70 | VSCEL+PIN |
| RSFP-4G31S-L1D | 4.25G | 1310 | SM | 10km | SFP | 0~70 | DFB+PIN |
| RSFP-4G31S-L3D | 4.25G | 1310 | SM | 30km | SFP | -20~85 | DFB+PIN |
| RSFP-4G31S-02D | 4.25G | 1310 | SM | 2KM | SFP | -20~85 | FP+PIN |
