100G QSFP28 ER4 1310nm 30km 40km duplex LC DOM module
- 1000 per Month
- T/T Credit Card
- 100G QSFP28 SR4 850nm MPO Multimode 100m QSF28 optical transceiver
- 100G QSFP28 to 4x25G SFP28 breakout passive copper cable direct attach DAC Cable
- Ubiquiti -OLT SFP 2.5GTx/1.25GRx 1490nmTx/1310nmRx Class C++ 20KM DDM SC SMF Module Transceiver
- huawei GPON-OLT SFP 2.5GTx/1.25GRx 1490nmTx/1310nmRx Class C+ 20KM DDM SC SMF Module Transceiver
- tplink GPON-OLT SFP 2.5GTx/1.25GRx 1490nmTx/1310nmRx Class B+ 20KM DDM SC SMF Module Transceiver
- Industrial grade 1.25G CWDM SFP 40km 1270-1610nm LC DDM modules
Product Description
100G qsfp28 ER4 1310nm 30km 40km Optical Transceiver
1. PRODUCT FEATURES
Hot pluggable QSFP28 MSA form factor
Compliant to Ethernet 100GBASE-ER4 Lite
Up to 25km reach for G.652 SMF without FEC
Up to 32km reach for G.652 SMF with FEC
Single +3.3V power supply
Operating case temperature: 0~70oC
Transmitter: cooled 4x25Gb/s LAN WDM EML TOSA (1295.56, 1300.05, 1304.58, 1309.14nm)
Receiver: 4x25Gb/s APD ROSA
4x28G Electrical Serial Interface (CEI-28G-VSR)
Maximum power consumption 5.0W
Duplex LC receptacle
RoHS-6 compliant
Operating case temperature:
Standard : 0 to +70°C
Industrial : -40 to +85°C
2.Applications
· 100GBASE-ER4 Ethernet Links
· Infiniband QDR and DDR interconnects
· Client-side 100G Telecom connections
3. Description
This product is a 100Gb/s transceiver module designed for optical communication applications compliant to Ethernet 100GBASE-ER4 Lite standard. The module converts 4 input channels of 25Gb/s electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for 100Gb/s optical transmission. Reversely on the receiver side, the module de-multiplexes a 100Gb/s optical input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of electrical data.
The central wavelengths of the 4 LAN WDM channels are 1295.56, 1300.05, 1304.58 and 1309.14 nm as members of the LAN WDM wavelength grid defined in IEEE 802.3ba. The high performance cooled LAN WDM EA-DFB transmitters and high sensitivity APD receivers provide superior performance for 100Gigabit Ethernet applications up to 25km links without FEC and 32km links with FEC.
The product is designed with form factor, optical/electrical connection and digital diagnostic interface according to the QSFP+ Multi-Source Agreement (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference.
Part Number |
Description |
QSFP+ 4*26G 30km, 0~70℃, with DDM |
Related 100G Optical transceivers list
CFP4
For STANDARD
Application Item No Description
Standard RB-CFP4-LR4 CFP4, 103/112 Gbps, 1310nm, SM, DDM, 6.3dB, 10km, LC
Shippment
Why Is Rollball ?
1.Quality system of ISO900,CE,FCC,ROHS registration
2.Manufacture system
3.R&D system
4.Purchasing system
5.Prompt delivery and remarkable services
6.Reasonable prices
7.Accept orders according to customer's demands
8.Rich experience of OEM & ODM co-operation
9.Shipment,payment and delivery
We sincerely invite all interested buyers to visit our company and contact us directly for further information, we will reply you within 12 hours!
