Brand compatible XFP-10G-LR 10G XFP 1310nm 10km XFP optical transceiver
1.Description
1).Rollball’s 10g xfp module are compliant with the current XFP Multi-Source Agreement (MSA) Specification. They comply with 10-Gigabit Ethernet 10GBASE-LR/LW per IEEE 802.3ae and 10G Fibre Channel 1200-SM-LL-L. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA.
2).The transceiver module comprises a transmitter with uncooled EML laser and a receiver with a PIN photodiode. 3).Transmitter and receiver are separate within a wide temperature range of 5°C to +70°C and offers optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10 GbE systems.
2.Applications
1).SDH STM I-64.1 at 9.953Gbps
2).10GBASE-LR/LW 10G Ethernet
3).1200-SM-LL-L 10G Fibre Channel
4).10GE over G.709 at 11.09Gbps
5).OC192 over FEC at 10.709Gbps
6).Other optical links, up to 11.1Gbps
3.Features
1).Dual LC pluggable optical port
2).XFP MSA compliant
3).OC192/STM-64 Eye mask compliant 6dB extinction ratio over temperature
4).850nm;1310nm;1550nm Laser diode transmitter
5).Protocol Agnostic: supports OC192/STM-64, 10 G Fibre Channel, G.709, and 10 G Ethernet
6).Applications from 100m to 80km
7).Stable output power over temperature (low tracking error)
8).Monitor Device Temperature and Voltage
9).-5 to 70 C temperature range
10).Die cast metal housing for low EMI
11).Supports DDMI function
12).Advanced Digital Diagnostics
13).Low power consumption
14).SIO Management Interface
15).RoHS compliant
4.Product list
| ||||||||||||||||||||||||||||||||||||||||||||||||
