RA6008 Cross Roller Bearing RA 6008 XRA 6008 Size 60x76x8
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
THK Cross Roller Bearing Thin Section Precision RA Series RA 5008 XRA 5008
-
XRU2512 UU Crossed Roller Bearings XRU2512 Slewing Bearing for Robot
-
Crossed Roller Bearings XRU3515 RU66 UU CC0 CC1 P5 P4 Robot Joint RU66UUCC0P5 Rotary Bearing
-
YRT-100 Rotary Table Bearing YRT100 YRT Slewing Bearing YRT-100
-
567411 High Quality 567411Cross Roller Bearing Z-567411
-
THK Rb Series Crossed Cylindrical Roller Bearings RB15030 RB15030UUCC0P5 XRB25030
Product Description
Product Description
Thin Type Roller Bearing RA 5008 6008 7008 8008 9008 C0 Clearance P5 grade
The Structure and Character of Cross Roller Bearingwe can offer the type of RA, RB, RE, RU, CRBH, SX，XSU, XV, SHF, CSF for industrial robots.
Crossed roller bearing is a special type bearing with split inner ring and outer ring rotation. The divided inner ring or outer ring is fixed with the cross roller collar after the roller and the spacer are installed to prevent separation, so the operation is simple when installing the cross roller collar.
because the inner or outer ring of the cross roller bearing has a two-part structure, the bearing gap can be adjusted, and even if a preload is applied, a high-precision rotary motion can be obtained. Moreover, due to its special structure, it can be applied to the joints and rotating parts of industrial robots, rotary tables of machining centers, rotating parts of manipulators, precision rotary tables, medical equipments, measuring instruments, IC manufacturing machines, etc.
Bearing Model | RA 6008 Crossed roller bearing |
Application | robots arm |
Type | Crossed Roller Bearing |
Structure | Separable Outer Ring Cross Roller Bearing |
(dxDxB) | 60x76x8 mm |
Mass / | 0.09 KG |
Origin | JAPAN |
Grade | P2 P4 P5 |
Lead Time | Within 3 Days |
Contact | jessi (Ms) |
WhatsApp / Webchat | +86 18753110215 |
E | lbc001at |
Detailed Images
THK RA6008UUCC0p5 Crossed roller bearing ra5008 pictures show
Model RA (Separable Outer Ring Type for Inner Ring Rotation) Based on model RB, this model is a light and compact type with the thinnest possible inner and outer rings. It is optimal for locations where weight reduction and downsizing are required, such as the hand swiveling unit of robots and manipulators.
crossed roller bearing RA5008 related bearings
thin crossed roller bearing RA5008 drawing
cross roller bearing RA 6008 models
Bearing NO. | Dimension(mm) | Weight (Kg) | ||||||
THK | IKO | d | D | B | ||||
RA5008 | CRBS508 | 50 | 66 | 8 | 0.08 | |||
RA6008 | CRBS608 | 60 | 76 | 8 | 0.09 | |||
RA7008 | CRBS708 | 70 | 86 | 8 | 0.1 | |||
RA8008 | CRBS808 | 80 | 96 | 8 | 0.11 | |||
RA9008 | CRBS908 | 90 | 106 | 8 | 0.12 | |||
RA10008 | CRBS1008 | 100 | 116 | 8 | 0.15 | |||
RA11008 | CRBS1108 | 110 | 126 | 8 | 0.16 | |||
RA12008 | CRBS1208 | 120 | 136 | 8 | 0.17 | |||
RA13008 | CRBS1308 | 130 | 146 | 8 | 0.18 | |||
RA14008 | CRBS1408 | 140 | 156 | 8 | 0.19 | |||
RA15008 | CRBS1508 | 150 | 166 | 8 | 0.2 | |||
RA16013 | CRBS16013 | 160 | 186 | 13 | 0.59 | |||
RA17013 | CRBS17013 | 170 | 196 | 13 | 0.64 | |||
RA18013 | CRBS18013 | 180 | 206 | 13 | 0.68 | |||
Application
Main Products
Certifications
Product packaging
Packing ：
1. Industrial packing
2. Single box +carton +pallets /case
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application
Factory
Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
