SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005

SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 thumbnail-1
SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 thumbnail-2
SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 thumbnail-3
SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 thumbnail-4
SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 thumbnail-5
SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 photo-1
SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 photo-2
SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 photo-3
SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 photo-4
SL04 5005 Sealed Double Row Full Complement Cylindrical Roller Bearings SL04 5005 PP NNF5005 photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2003
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Jinan Landlion Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description
SL04 5005 Sealed double row full complement cylindrical roller bearings SL04 5005 PP NNF5005
The bearings have solid outer and inner rings and rib-guided cylindrical rollers.Since these bearings have the largest possible number of rolling elements, they have extremely high radial load carrying capacity, high rigidity and are suitable for particularly compact designs. Due to the kinematic conditions, however, they do not achieve the high speeds that are possible when using cylindrical roller bearings with cage.Double row full complement cylindrical roller bearings are available as non-locating,semi-locating and locating bearings. The bearings do not permit any skewing between the inner and outer ring , are supplied in an open design.

SL 04 5005 PPbearings are widely used in mining , petroleum , marine,chemical,coal,cement,heavy machinery ,wind power,engineering machinery and other industries . We can also supply interchangable bearing NNCF ,NNC and NNCL series .If you want to know more about SL18 5004 bearing , pls do free to contact us .
Cylindrical roller bearing are of high load capacity and can operate at high speeds because they use rollers as their rollingelements. They can therefore be used in applications involving heavy radial and impact loading.
Sealed double row full complement cylindrical roller bearings SL04 5005 PP
Name
Sealed double row full complement cylindrical roller bearings SL04 5005 PP
ID
25mm
OD
47mm
B
30mm
bearing weight
0.24g
Application
gear box
Tel
86-18710180456
contact
sales1@landlionbearing.com
Recommend Products
d
D
B
weight KG
new bearing model
Old bearing model
20
42
30
0.2
SL04 5004 PP
NNF 5004 ADB-2LSV
25
47
30
0.24
SL04 5005 PP
NNF 5005 ADB-2LSV
30
55
34
0.37
SL04 5006 PP
NNF 5006 ADB-2LSV
35
62
36
0.48
SL04 5007 PP
NNF 5007 ADB-2LSV
40
68
38
0.56
SL04 5008 PP
NNF 5008 ADB-2LSV
45
75
40
0.7
SL04 5009 PP
NNF 5009 ADB-2LSV
50
80
40
0.76
SL04 5010 PP
NNF 5010 ADB-2LSV
55
90
46
1.2
SL04 5011 PP
NNF 5011 ADB-2LSV
60
95
46
1.25
SL04 5012 PP
NNF 5012 ADB-2LSV
65
100
46
1.35
SL04 5013 PP
NNF 5013 ADB-2LSV
70
110
54
1.85
SL04 5014 PP
NNF 5014 ADB-2LSV
75
115
54
1.95
SL04 5015 PP
NNF 5015 ADB-2LSV
80
125
60
2.7
SL04 5016 PP
NNF 5016 ADA-2LSV
85
130
60
2.85
SL04 5017 PP
NNF 5017 ADA-2LSV
90
140
67
3.7
SL04 5018 PP
NNF 5018 ADA-2LSV
95
145
67
3.9
SL04 5019 PP
NNF 5019 ADA-2LSV
100
150
67
3.95
SL04 5020 PP
NNF 5020 ADA-2LSV
110
170
80
6.45
SL04 5022 PP
NNF 5022 ADA-2LSV
120
180
80
6.9
SL04 5024 PP
NNF 5024 ADA-2LSV
130
190
80
7.5
SL04 130 PP
319426 DA-2LS
130
200
95
10.5
SL04 5026 PP
NNF 5026 ADA-2LSV
140
200
80
8
SL04 140 PP
319428 DA-2LS
140
210
95
11
SL04 5028 PP
NNF 5028 ADA-2LSV
150
225
100
13.5
SL04 5030 PP
NNF 5030 ADA-2LSV
160
220
80
8.8
SL04 160 PP
319432 DA-2LS
160
240
109
16.5
SL04 5032 PP
NNF 5032 ADA-2LSV
170
230
80
9.3
SL04 170 PP
319434 DA-2LS
170
260
122
22.5
SL04 5034 PP
NNF 5034 ADA-2LSV
180
240
80
9.8
SL04 180 PP
319436 DA-2LS
180
280
136
30
SL04 5036 PP
NNF 5036 ADA-2LSV
190
260
80
12.5
SL04 190 PP
319438 DA-2LS
190
290
136
31.5
SL04 5038 PP
NNF 5038 ADA-2LSV
200
270
80
13
SL04 200 PP
319440 DA-2LS
200
310
150
42
SL04 5040 PP
NNF 5040 ADA-2LSV
220
340
160
53.5
SL04 5044 PP
NNF 5044 ADA-2LSV
240
360
160
57.5
SL04 5048 PP
NNF 5048 ADA-2LSV
260
340
95
22.5
SL04 260 PP
-
300
380
95
25.5
SL04 300 PP
-
Boundary dimensions
Mass
Bearing NO.
Interchangable NO.
(mm)
(kg)
d
D
B
LSBC
20
42
30
0.2
SL18 5004
NNCF 5004 CV
25
47
30
0.23
SL18 5005
NNCF 5005 CV
30
55
34
0.35
SL18 5006
NNCF 5006 CV
35
62
36
0.46
SL18 5007
NNCF 5007 CV
40
68
38
0.56
SL18 5008
NNCF 5008 CV
45
75
40
0.71
SL18 5009
NNCF 5009 CV
50
80
40
0.76
SL18 5010
NNCF 5010 CV
55
90
46
1.15
SL18 5011
NNCF 5011 CV
60
85
25
0.48
SL18 4912
NNCF 4912 CV
60
85
25
0.49
SL01 4912
NNC 4912 CV
60
85
25
0.47
SL02 4912
NNCL 4912 CV
60
95
46
1.25
SL18 5012
NNCF 5012 CV
65
100
46
1.3
SL18 5013
NNCF 5013 CV
70
100
30
0.77
SL18 4914
NNCF 4914 CV
70
100
30
0.78
​SL01 4914
NNC 4914 CV
70
100
30
0.75
SL02 4914
NNCL 4914 CV
70
110
54
1.85
SL18 5014
NNCF 5014 CV
75
115
54
1.95
SL18 5015
NNCF 5015 CV
80
110
30
0.87
SL18 4916
NNCF 4916 CV
80
110
30
0.88
SL01 4916
NNC 4916 CV
80
110
30
0.85
SL02 4916
NNCL 4916 CV
80
125
60
2.6
SL18 5016
NNCF 5016 CV
85
130
60
2.7
SL18 5017
NNCF 5017 CV
90
125
35
1.35
SL18 4918
NNCF 4918 CV
Product packaging
Packing ： 1. Industrial packing 2. Single box +carton +pallets /case 3. According to customers demand Delivery time : 1. Generally after payment: within 3 days . 2. If need produce , about 30 days Payment A less USD1000 , 100% T/T in advance . 1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application
Factory
Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
FAQ
Q: Are you trading company or manufacturer ? A: We are factory and trader . Q: How long is your delivery time? A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q: What is your terms of payment ? A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment. If you have another question, pls feel free to contact us .
