Hight Speed Advertising Knife Cutting Machine For Sale 1325 Cnc Oscillating Cnc Cloth Cutting Machine

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Hight Speed Advertising Knife Cutting Machine For Sale 1325 Cnc Oscillating Cnc Cloth Cutting Machine

SOFIA Series Knife-visual positioning multi-function cutting machine is an upgraded version. The whole machine adapts to high quality and high precision parts. The machine adopts the oscillating knife and high-speed spindle, Digital ALigned cutting system, JMC hybrid servo motors with Japan SHIMPO precise reducer and drives, High-density bakelite plate and T-slot table with 4.5kw Air cooling vacuum pump.
Optional tangential knife
The tangential knife is the more robust of the two options, intended for processing heavier, thicker and harder materials than a traditional drag knife can accommodate. A selection of easily interchangeable blade cartridges allow a wide range of material to be processed. Full directional control of the blade allows straight edges, sharp corners and all radii to be cut cleanly and accurately.

Features of SOFIA OKC CNC Router:

1/ The bed is made of high-rigidity rectangular steel pipe welded and optimized dragnet structure, aging treatment to ensure the precision of the bed.

2/ Independent double heads device--spindle and oscillating knife, can be cut according to different materials.

3/ Excellent visual positioning system, one-click cutout and one-click start processing, free of typesetting&cutout time, improve processing efficiency.

4/ Oscillating knife head can be processed and tracing-edge cutting according to different materials, the material dust-free and without raw edge.

Specification

Model	Sofia1325-OKC
Working area	13002500200mm
X, Y axis Transmission device	1.25M helical rack gear transmission
Z axis Transmission device	Taiwan TBI ball screw 2005
Table structure	T-slot&Vacuum table+Clamp device+Vacuum pump
Travel speed	0-35000mm/min
Max. Power Consumption	(Without Spindle) 5.5kw
Spindle power	4.5kw air spindle+ER32 cutter
Spindle speed	Spindle speed
Diameter of cutter	φ3.175-φ12.7mm
Drive Motors	Hybrid servo motor&driver+Reducer structure
Command code	hPGL G-code
Working voltage	AC220V/50/60Hz, 3PH (Option: 110V, 380V)
Device interface	Standard PCI/USB interface Optional
Control system	Xingduowei/Multech controller
Resolution	0.01mm
Machine size	193530151500mm
Machine weight	1500kg
Running Environment Temperature	0 - 45 Centigrade
Relative Humidity	30% - 75%

Applications

Application of SOFIA CCD CNC Router
CCD control system, one-key extraction of contours, simple and convenient operation. Tracing-edge cutting for different materials, such as KT board, PVC, photo paper to achieve no burr cutting. Equipped with professional 1.5 million pixels industrial camera, powerful image recognition, more accurate cutting.

Company Profile

"///UTECH" is the new logo brand after the transformation of "Shandong U-May CNC Technology Co., Ltd.". "///" aims to record the important strategic transformation of the company from ordinary business innovation to high-quality operation in the three years after its establishment; "U" is "U-May"'s homophonic characters; "TECH" means the CNC technology. At the same time, when the company was founded three years, the establishment of the Ministry of Foreign Trade, so "///UTECH" became the company's new logo, and the company's development philosophy "Smarter Solution, Better Tomorrow."

Our Service

Our service professionals can help you: 1. Diagnose and troubleshoot. 2. Assess machine performance. 3. Identify components. 4. Mount and/or remove components. 5. Review software and control system. 6. Optimize equipment performance.

Packing & Delivery

All the CNC router machines can be shipped worldwide by sea, by air or by international express logistics via DHL, FEDEX, UPS. You are welcome to get a free quotation by filling up the form with name, email, detailed address, product and requirements, we will shortly contact you with the full information including the most suitable delivery method (fast, secure, discreet) and freight. A CNC router machine firstly should be packaged well in a wooden crate. Usually, we deliver the CNC machine by ship, sometimes, as customer's requirements, we can also deliver by air or by train. When the CNC machine arrived at your sea port or destination, you can pick up with the bill of lading we offered. We can also arrange the cargo agent to send to your door.
