2513 3 Axis Cnc Wood Machine for Aluminum 7.5KW Water Cooling Spindle Motor cnc wood router manufacturer

Because the accuracy of cnc router machine greatly depends on the spindle. The High-quality SESAME series CNC Router machine comes with 3.2kw water or 3.5 air cooled high-frequency spindle. This precision spindle requires no maintenance, uses industry standard ER collects. Fully programmable speeds from 6000 to 24000RPM, and comes complete with pneumatically retractable vacuum hood.

The whole electrical system is consisting of a CNC machine, variable frequency drive, time relay, and brake assembly.
We adapt 3.7kw VFD, Greatly improve the machining accuracy and production efficiency of CNC machine, play an important role in product quality improvement, production increase, cost decrease, automation level increase, and maintenance reduced.

Vacuum tables are devices that use suction to securely hold work pieces during machining. They are most commonly used during CNC cutting, whether with a mill or router or with a drag knife. They can be various sizes, and they are comprised of a perforated table top connected to the vacuum chamber, and a vacuum pump that continuously applies suction.

TBI High-Precision Ball-screw Transmission (Taiwan)

Precision 1.25 module helical rack gear.

Helical teeth gears provide continuous engagement along the tooth length and are often quieter and more efficient than straight tooth gears and also offer higher loading for same rack width. Helical tooth gears resemble spur gears in the plane of rotation but include teeth that are twisted along a helical path in the axial direction.

PMI Linear guide+High assembly Flange slider
(1)High positioning accuracy, high repeatability
(2) Low frictional resistance, high precision maintained for the long period
(3) High rigidity with four-way load design
(4) Suitable for high-speed operation
(5) Easy installation with interchangeability

The stepper motors are installed on all axes to ensure precise positioning of the gantry and the spindle in accordance with a predetermined program at high speed. Stepper motors are well proven high degree of reliability.
The machine is installed 4 sets of motors and Driver. Y-axis

use double motors drivers way.

Patent design 1:4 gear reducer install on the driving motor, makes the motor is more powerful, and having a long time service life.

Selecting a chopper driver and configuring it for a specific motor requires a good understanding of both the motor and the controller. Mismatched motors and drivers can result in disappointing performance. Or worse: damage to the motor and/or controller. we deal with the most important part: making sure that your motor and driver are compatible

The handle is equipped with 3.5 inch TFT color display screen, 4 indicator lamps, 1 emergency stop switch and 36 keys. There is a USB interface on the right to connect to the U disk, and a DB-25 interface on the bottom.

This device takes the guesswork out of tool changes and ensures that every tool path that you run is accurate. Consistent Z height across tool changes is critical, especially when running multi-tool jobs like cabinet work, raised panel doors and intricate 3D carving projects.
CNC Tool Sensor allows for easy and accurate "Z" zero position for single and multiple tool changes through the program.

Protecting machinery is an ongoing responsibility. To guarantee high performance over the course of time requires both long-term and spontaneous maintenance. A manual lubricator not only distributes grease or lubrication for a variety of large machinery, but it also allows operators to do so in a timely manner.

There is double insurance emergency stop switch. In case of any emergency, the worker can press any emergency stop button and the machine will stop working.

According to overseas custom demand and market research, as for the overall design structure of the bed body, we adopt separated type lathe bed structure. With the purpose of After ensuring that the customer receives the equipments, there's no need to make a complete disassembly and will not affect the operation of the equipment. In this circumstance, we optimized the design structure, then, the final packaging size of the product was saved by 5 cubic meters. Thus saving transportation costs.

The machine main body and the machine legs are freely separable when delivery the legs are disassembled and put on the table, which will reduce the machine's package size, then will save the shipping cost.

The bed is the backbone of a cnc router machine, our machine bed adapts 200*300mm thick wall steel square tube welded together, solid and not deformed. After high temperature tempering treatment to ensure the best strength and rigidity side arranged structure, heavy column,150*150mm gantry. precision machined and stress relieved so that the foundation remains true and steady over the operational life of the machine. Compared to ordinary machines, it has better stability.

The forklift location display of Sesame CNC router machine.
Bed welding process increases the reserved forklift space, highlights two major advantages: First, it can better protect machine body and cargo carrying weight; Second, it's more convenient for customers to load or unload the equipment.

The Spindle Mounting Plate of Sesame adapts High Precision aviation aluminum alloy parts T6061/6030, Which are all made by professional CNC machining center. After the oxidation surface and low-temperature annealing treatment, the machine head is lighter and more durable. And the high requirement assembly process ensures the precision of the product again.

Sesame adapts Portable detached optional design control cabinet.

1)Interfacing reaches the purpose of plug and play.

2)Save more space.
