Small Cnc Router 3030 4 Axis Rotary 3D Milling Machine
- 1000 per Month
- T/T Credit Card
- Good quality cnc router machine for woodworking 3d
- EASY to operate multi heads rotary 4 axis cnc wood router 1212 woodworking machinery
- 1325 4axis cnc router machine cabinet door woodworking machinery
- 6090 3 axis cnc router wood engraving machine
- 1530 3d wood cnc router woodworking machinery
- 4040 6060 6090 Mini Desktop Wood Acrylic Engraving Small Aluminum Mould CNC Router Machine
Product Description
Mini Cnc Router 4 Axis 3030 Milling Machine
1. Remax-3030 4 axis cnc router use March 3 control system,
2. For the rotary axis configurate with reducer, so it can stop at any angel.
3. The whole machine is cast iron, so it can process metal kind of materials, it also can engrave wood, MDF, acrylic, stone, aluminium, copper etc.
1)Whole machine cast by iron, very strong and never out of shape
2)Leadshine driver and motor, Schneider electrical parts
3)TBI ball screw transmission ensures high accuracy
4)Imported square rail ensures high accuracy and heavy workload
5)MACH3 / DSP control system, easy cooperation
6) 4 axis rotary axis can carve cylindrical materials, pillars etc.
Description | Remax 3030 small cnc router 4 axis milling machine |
X,Y,Z Working area | 300*300*200mm |
S,Y,Z Traveling positioning Accuracy | ±0.02mm |
Table Surface | T-slot Iron table |
Frame | Cast iron Structure |
X,Y Structure | Hiwin Rail Linear Guide |
Z Structure | TBI Ball Screw |
Max power Consumption | (Withou Spindle)2.2 KW |
Max Rapid Travel Rate | 20000mm/min |
Max Working speed | 10000mm/min |
Spondle power | 1.5/2.2 /3.2 water cooling spindle |
Spindle speed | 0-24000RPM |
Working Voltage | AC220v/380V, 50/60Hz |
Command Language | G code |
operating System | Mach3 /DSP / NC studio control system |
Computer interface | USB |
Flash memory | 128M(u disk) |
Software compatibility | Type3/Artcam |
Running Environment Temperature | 0-45 Centigrade |
Relative Humidity | 30%-75% |
Inverter | Delta/Fuling |
Electrical components | Schneider |
Limit switch | OMRON |
Motor and Driver | stepper motor and Leadshine driver |
Jinan Remax Machinery Technology Co., Ltd specializes in the development and manufacture of CNC
router machines, CNC laser machine, CNC plasma cutting machine.
Our company sets research and development, production, sales, maintenance services as a whole,
Our products have covered advertising industry, woodworking industry, craft gifts, architectural models,
electronics, CAD / CAM industry mold industry, decoration, clothing, packaging, printing, dyeing, logos,
seals, etc industries; and because of its distinct cost-effective domestic and in various application fields
have been completely replacing imported similar products.
The company will continue to adopt international advanced production technology and production processes,
development and production of high quality, the high price ratio of numerical control equipment, continuing
to create maximum value for customers.
We not only produce machines, we provide the best solution for you.
We are looking forward to long-term cooperation.
1 we are a real factory offering products
2 free technical advice by QUALIFIED MECHANICAL ENGINEERS
3 company in business for many years
4 over 50 countries customers served!
5 buy direct saving your money!
6 all machine with CE, ISO, BV certificate.
7 machine and spindle warranty 1 year.
8 our engineer can go to your country to provide technical guidance
9 we have phone support in English, if you have any questions, you can call it,
we can give you a best solution within 24 hours
10 fast delivery, save your time.
Packaging Details
If export to european countries, the wooden box will be fumigated.If container is too tigher, we will use pe film
for packing or pack it according to customers special request.
1.Question:This is the first time I use this kind of machine, is it easy to operate?
Our Answer:
There are English manual or teaching video that show how to use machine.If there is
still have any question, please contact us by whats app/ e-mail / skype/ phone online service
at any time.
2.Question :If machine have any problem after I receive it, how can I do ?
Our Answer:
Free parts send to you in machine warranty period if machine have any problem.
3.Question: MOQ ?
Our Answer:
the minimum order is 1 set machine, if you order more one time, the price will be better.
4.Question:D How can I buy this machine from you? ( Very easy and flexible !)
Our Answer:
1. Consult us about this product on line or by e-mail.
2. Negotiate and confirm the final price , shipping , payment methods and other terms.
3. Send you the proforma invoice and confirm your order.
4. Make the payment according to the method put on proforma invoice.
5. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
6. Send your order by air or by sea.
5.Question: good reasons why you should buy from us?
Our Answer:
1 we are a real factory offering products
2 free technical advice by QUALIFIED MECHANICAL ENGINEERS
3 company in business for many years
4 over 50 countries customers served!
5 buy direct saving your money!
6 all machine with CE, ISO, BV certificate.
7.Total machine for one year guarantee
8 our engineer can go to your country to provide technical guidance
9 fast delivery, save your time.
