1325 Double Head 4axis Cnc Router Machine With Vacuum Table
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1993
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1530 Cnc Wood Carving Engraving Cutting Router Machine in JinanNegotiableMOQ: 1 -
2030 ATC 3 Axis Wood Cutting Machine Cnc RouterNegotiableMOQ: 1
-
China Cheap Mini Desktop Small Cnc Router 3030 MachineNegotiableMOQ: 1
-
Low Cost Cnc Routers 1500x2500mm Cnc Stone Cutting Machine for Gypsum Foam PlasticNegotiableMOQ: 1
-
Cnc Routers Machines 1325 Wood Working Atc Cnc Router for Metal and NonmetalNegotiableMOQ: 1
Product Description
1325 double head 4axis cnc router machine with vacuum table
Main Features
Application
1.Two air cooling spindle good for process wood.
2.Two spindle separately can do different work at different time.
3.Two rotary axis can do same work at same time which improve the work efficiency.
4.Strong structure with over 6mm steel pipe welded.
5.Rotary axis for 200mm diameter, can process legs, upstairs, gun handle.
Description |
Parameter |
||||||
Product name |
1325 double head 4axis cnc router machine with vacuum table |
||||||
X,Y,Z Working Area |
1300x2500x350mm |
||||||
X,Y,Z Accuracy |
±0.02mm |
||||||
X,Y,Z Repositioning Accuracy |
±0.0254mm |
||||||
Table Surface |
T-slot and vacuum Table |
||||||
Frame |
Machine welded by steel |
||||||
Transmission |
Hiwin square rail and rack gear |
||||||
Max. Power Consumption |
2.5kw~5Kw (without spindle) |
||||||
Max. Rapid Travel Rate |
40m/min |
||||||
Max. Working Speed |
25m/min |
||||||
Spindle Power |
HQD 4.5kw air cooling spindle |
||||||
Spindle Speed |
0-18000RPM |
||||||
Driver and Motor |
Stepper Motor or servo motor |
||||||
Working Voltage |
AC 220V/380V 50/60Hz |
||||||
Command Language |
G Code |
||||||
Operating System |
DSP A18 System |
||||||
Computer Interface |
USB |
||||||
Software |
Type3 or Artcam |
||||||
Running Environment Temperature |
0 - 45 Centigrade |
||||||
Relative Humidity |
30% - 75% |
||||||
Inverter |
Delta/Fuling |
||||||
Electrical components |
Schneider |
||||||
Limit switch |
OMRON |
||||||
Tool sensor and lubrication |
With |
||||||
Rotary axis |
200*2500mm |
||||||
Detailed Images
Sample
Certifications
Our Company
Jinan Remax Machinery Technology Co., Ltd specializes in the development and manufacture of CNC router machines, CNC laser machine, CNC plasma cutting machine.
Our company sets research and development, production, sales, maintenance services as a whole,Our products have covered advertising industry, woodworking industry, craft gifts, architectural models, electronics, CAD / CAM industry mold industry, decoration, clothing, packaging, printing, dyeing, logos, seals, etc industries; and because of its distinct cost-effective domestic and in various application fields have been completely replacing imported similar products. The company will continue to adopt international advanced production technology and production processes, development and production of high quality, the high price ratio of numerical control equipment, continuing to create maximum value for customers.
We not only produce machines, we provide the best solution for you.
Remax looking forward to being your partner.
Our Service
Guarantee:
1. Two years for the whole machine.
2. Within two years under normal use and maintenance, If something is wrong with machine, you will get spare part for free.
3. Out of two years, you will get spare part at cost price.
4. You will also get technical support and service all the lifetime.
Technical support:
1, Technical support by phone, email or MSN/Skype 24 HOURS
2, Friendly English version manual and operation video CD disk
3, Engineer available to service machinery overseas
After sales services:
1 Normal machine is properly adjusted before dispatch.
2 You will be able to use the machines immediately.
3 You will be able to get free training advice towards our machine in our factory.
4 You will also get free suggestion and consulting, technical support and service by email/fax/tel and lifetime technical support.
