Big Size Plasma 2040 2060 Cnc Aluminium Router and Plasma Flame Cutting Machine With Starfire Cnc Control Nozzle P80
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2004
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Jinan LEEDER Cortador de Plasma Cnc Plasma Mesa de Corte 120a in BrasilNegotiableMOQ: 1 -
China Supplier 1530 1560 Metal Sheet Plasma Cutting Machine Air Plasma Cutter Cut 80 Cut 100NegotiableMOQ: 1
-
1530 Cnc Plasma Cutter Nozzle Tip Plasma Table Cutting Machine 220v for Steel CuttingNegotiableMOQ: 1
-
Jinan LEEDER Mquina de Corte Cnc Por PlasmaNegotiableMOQ: 1
-
High Precision Multi Function Plasma Cutting 60a Cnc Plasma Cutting and Drilling MachineNegotiableMOQ: 1
Big size plasma 2040 2060 cnc aluminium router and plasma flame cutting machine with starfire cnc control nozzle p80
Product Description
Machine Features
# The beam uses light structural design,with good rigidity structure, welded lathe bed of thick profiled steel, more solid and stable.
# The gantry structure, Y axis used dual-motor dual-driven system,X,Y,Z axis all use dual-straight rail that make the machine driving smoothly with high-precision.
# Support FASTCAM nesting software such as the standard G code path generated file can also be also can change software to read AUTOCAD softwares produce DXF form documents. U disk exchange control system processing files, easy to operate.
# Aiming at cutting three dimension LED character, trough metal panels and floor cutting, the accuracy can reach good indicators.If it equipped with United States Hypertherm plasma source the machine can reach threshold.
# Advanced material inclined discharging design.
# The gantry structure, Y axis used dual-motor dual-driven system,X,Y,Z axis all use dual-straight rail that make the machine driving smoothly with high-precision.
# Support FASTCAM nesting software such as the standard G code path generated file can also be also can change software to read AUTOCAD softwares produce DXF form documents. U disk exchange control system processing files, easy to operate.
# Aiming at cutting three dimension LED character, trough metal panels and floor cutting, the accuracy can reach good indicators.If it equipped with United States Hypertherm plasma source the machine can reach threshold.
# Advanced material inclined discharging design.
Specification
Model | LEP-1530 |
Working size | 1500x3000mm |
Working material | Iron,Carbon/Stainless Steel, Aluminum,Galvanized sheets,Titanium Plates, Brass |
Cutting thickness | 0-40mm(flame head can cut max.200mm) |
Cutting speed | 1-10000mm/min |
Working power | 8.5-15KW |
Input voltage | 3 Phase 380V |
Plasma power | 63A/100A/120A/160A/200A/300A (Hypertherm 45A/65A/85A/105A/125A/200A) |
Control system | Starfire control system |
Command | G code, *uoo, *mmg, *plt |
Operation language | Support multi-language |
Software | Fastcam software |
To cut all metals, including but not limited to aluminium sheet, iron sheet, galvanized (steel) sheet, mild steel,titanium sheet.stainless steel, iron etc.
Please Kindly tell us the Cutting Materials, the maximum working area and the cutting depth. According to this,we suggest most suitable machine for you.
Please Kindly tell us the Cutting Materials, the maximum working area and the cutting depth. According to this,we suggest most suitable machine for you.
