Multi-process pneumatic 4 spindles woodworking cnc 1325 wood door making pneumatic cnc router cutting machine
# It adopts a new-style generous square tube,The four-process cutting machine has four spindles to automatically change suitable tools, which saves tool changing time and has high efficiency.
# Vacuum adsorption table, high adsorption force, processing does not run off the board.
# XY axis helical rack and Z axis adopts Taiwan TBI ball screw with high precision.
# Taiwan square rails All three axes adopt original linear square rails, which have good stability and high precision.
# When the types of tools required to process the workpiece are four or less, it is recommended to choose a four-process cutting machine.
CNC router machine 1325 parameter:
|
NO. |
Model |
1325 |
|
1 |
Working area |
1300x2500x200mm |
|
2 |
Working table |
Vacuum absorb table with T-slot |
|
3 |
Spindle |
3kw/4.5kw/5.5kw/6kw air cooling spindle |
|
4 |
Cooling system |
Air cooling |
|
5 |
Control system |
NC Studio/DSP/MARCH3 |
|
6 |
Inverter |
Fuling inverter |
|
7 |
Transmission |
XY-axis Rack gear,Z-axis ball screw |
|
8 |
Guide rail |
Taiwan Square HIWIN guide rail |
|
9 |
Ball screw |
Taiwan TBI ball screw |
|
10 |
Drive system |
Servo motor and driver |
|
11 |
Machine body |
Square tube welding body |
|
12 |
Limit Switch |
Japan Omron |
|
13 |
Electrical components |
France Schneider |
|
14 |
Traveling speed |
30m/min |
|
15 |
Working speed |
20m/min |
|
16 |
Control software |
Artcam/Type3,other CAD/CAM |
|
17 |
Command code |
G Code*.u00*.mmg*.plt |
|
18 |
Voltage |
AC220V/380V-50HZ/60HZ |
|
19 |
Color |
Optional |
Three years warranty for the whole machine. Within 18 months under normal use and maintenance, if something is wrong with the machine, you will get spare part for free. Out of 18 months, you will get spare parts at cost price. You will also get technical support and service all the lifetime.
Technical support:
1. Technical support by phone, email or WhatsApp/Skype around the clock
2. Friendly English version manual and operation video CD disk
3. Engineer available to service machinery overseas
After sales services:
Normal machine is properly adjusted before dispatch. You will be able to use the machine immediately after received machine.
Besides, you will be able to get free training advice towards our machine in our factory. You will also get free suggestion and consultation, technical support and service by email/WhatsApp/tel etc
