Automatic filling machine for sauce paste product information Automatic filling machine for sauce paste product introduction: Automatic filling machine for sauce paste is a special type of automatic packaging machine widely used in food, medicine, chemical industry, condiment, hot pot seasoning, oil and other industries. The packaging production equipment condenses our company's successful technical experience in the automatic packaging industry for many years, draws on the valuable opinions and suggestions of a large number of users, and constantly improves the updated and batch-produced fully automatic powder packaging production equipment that reaches the standard. The machine has the characteristics of high measurement accuracy, fast packaging speed, no sealing pollution, prevention of material filling and drawing, and beautiful bag shape.
Process flow of automatic filling machine for sauce paste: materials to be packaged are injected into cold and hot tanks (including automatic stirring device)-----------rotor pump automatically pumps materials to high-level stirring tank (controlled by the material level of stirring tank)-------XY-YG sauce filling machine automatically measures and fills according to the set weight--------XY series automatic filling.
Technical parameters of automatic filling machine for sauce paste: packing materials: uniform fine particles and viscous fluid materials (hot pot seasoning, sauce, oil bag, butter and other materials).
Packing speed: 15 ~ 30 packs/min (depending on the material state and packing weight)
Measuring range: 100 ~ 500 g
Bag size: length (50-320) x width (60-200) mm (XY-420 unit)
Measurement accuracy: 0.5 ~ 3%
Compressed air: 0.6Mpa 0.65m3/min
Allowable * Outer diameter of wrapping material: φ Φ400mm
Paper core inner diameter: φ Φ75mm
Machine weight: 800Kg
Power supply: 5.5Kw 380V±10% 50Hz
Type: back-sealed bag
Packaging material: composite film.
