SENKE Granite bricks stones Double heads Table Saw Stone Cutting Machine Large Stone Cutting Machine

Product Description

 Features:

1. Integrally cast lathe bed, firm and non-deforming, high rigidity and high accuracy, adopts Taiwan line guide rail.

2. Use high speed drive motor,also servo motors for optional

3. Memory function ensures the processing point when the blade is broken or having to postpone the process.
4. With better compatibility, can math with many programs such as Typle3, artcam,

castmate, proE, Coreldraw/CAD, CAM. It achieves 2D and 3D works easily.

5. Dust protector and waterproof design ensure stable transmission.



Technical parameters:



Description

Parameter

SKS-9015

SKS-1325

SKS-1530

Option

Working Area (X*Y*Zmm)

900*1500*200

1300*2500*200

1500*3000*200

Customized

Body structure

T-Steel tube

X, Y Structure

rack and pinion drive

Z structure

gear rack/  Ballscrew optional

Max Moving Speed

30000mm/min

XYZ traveling positioning accuracy

0.04

XYZ repositioning accuracy

0.04mm

Spindle Speed

0-24000rpm

Spindle power

2.2KW/3.0kw/4.5kw watercooling

voltage

AC220V/50Hz or can be customized

Drive motor

Steppter/option servo motors

Command language

G code,HPGL

Control system

DSP option NC-Stuido

Software Compatibility

Type3, Ucancam,Artcam Software



machine parts

 SENKE Granite bricks stones Double heads Table Saw Stone Cutting Machine Large Stone Cutting Machine



samples

 SENKE Granite bricks stones Double heads Table Saw Stone Cutting Machine Large Stone Cutting MachineSENKE Granite bricks stones Double heads Table Saw Stone Cutting Machine Large Stone Cutting Machine



Company Information



SENKE Granite bricks stones Double heads Table Saw Stone Cutting Machine Large Stone Cutting Machine




Packaging & Shipping



SENKE Granite bricks stones Double heads Table Saw Stone Cutting Machine Large Stone Cutting Machine

SENKE Granite bricks stones Double heads Table Saw Stone Cutting Machine Large Stone Cutting Machine



why choose senke

Warranty

 As manufacturer directly,SenKe promise for their quality,senke proved 2 years warranty for we products

Operation



All senke machine sending with software CD,software manual,teaching video,machine operate manual,packing list,if you want view first,please kindly contacted we seller directly,we send by email



 Videos



If you want check,how the machine work,please kindly contact we seller,we will send to you senke router working video.



Training



We senke team was constituted by skilled staff,anyone of them with years experience,can operate all style control system machine skilled and adept,if you needed,we engineer oversea services available,detailed charges please contacted we seller,also if you like,welcome to us,in we factory,the training service itself free.



Email id



All senke seller use the uniformed email id,that end with @senkecnc.com,we whole team supply the experienced and knowledgeable technical support specialists.
