Product Description Usage Bag-feeding packaging machine is suitable for automatic metering and bagging of particles, powder, liquid, sauce and other materials after matching with different meters (such as combination scales and screw scales).
Features Easy operation: PLC control, man-machine interface;
Variable frequency speed regulation: using variable frequency adjustment device, the speed can be adjusted at will within the specified range; Easy to adjust the width of the bag: it is controlled by the motor, and only one button can be used to adjust 6 groups of machine clips synchronously; Adopt oil-free vacuum pump to avoid production environment pollution; The parts in contact with the materials are all made of 304 stainless steel, which meets the food hygiene standards; Easy cleaning: the machine table can be washed. The safety device has no bag or incomplete bag opening, and no feeding is required; No bag or filling, no sealing; Open door alarm (optional); Colorless shutdown alarm; Insufficient air pressure, alarm prompt; Abnormal sealing temperature, alarm prompt.
technical parameter
model
GD6-200C
GD6-250C
GD6-300C
station
Six stations
Bag material
complex film
Bag type
Self-standing bag, inclined mouth bag, flat bag (three-sided, four-sided, hemmed bag, etc.)
Bag size
W:100-210mm
L:100-350mm
W:150-260mm
L:100-350mm
W:200-300mm
L:100-450mm
speed
10-60bag/min
10-50bag/min
10-50bag/min
weight
1000KG
1200KG
1300KG
voltage
380V 3phase 50HZ/60HZ
power
2.5KW
3.5KW
3.5KW
compressed air
0.6m³/min (supplied by user)
