Help CenterMini Aerosol Fire Suppression System for Vehicle Engine Room
Related Products
-
Lithium Battery Pack Aerosol Fire Extinguisher QRR0.012G-S-SAUS$ 11 - 20MOQ: 10 Pieces -
Mini Style Electrical Cabinet Fire Extinguishing System Aerosol GeneratorUS$ 1 - 2MOQ: 10 Pieces
-
Lithium Battery Pack Aerosol Fire Extinguisher AW-QRR0.012US$ 0.001 - 0.002MOQ: 10 Pieces
-
Portable Aerosol Fire Extinguisher PSE-2US$ 25 - 26MOQ: 1 Piece
-
Electrical Cabinet Fixed Aerosol Fire Extinguishing DeviceUS$ 1 - 2MOQ: 100 Pieces
Name of Product: Electric start-up aerosol
Part Number: 20G to 5700G.
Dimensions: Diameter range from 50 mm to 220 mm.
Total weight: range from 0.85 kgs to 30kgs.
Weight of aerosol compound: 20 grams to 5700 grams.
Volume coverage: range from 0.2m³ to 57m³.
Discharge Time: less than 40 seconds.
Activation current: 150 to 250 mA.
Power supply: AC 3 to 24 Volt, DC 3 to 220 Volt.
Product cylinder color: Silver-white, 304 stainless steel.
Fire Suppression type: Class A, Class B, Class C, and Class E.
Product Life: 10 years, and even can reach 15 years if the installation environment is dry.
DESCRIPTION
The electric start-up aerosol fire extinguishing systems are ideal solutions for wind turbine and vehicle engine fire protection, because it is mini and versatile to install in these narrow and limited space.
In China, almost 90% of wind turbines use our aerosol suppression systems, we install our aerosol in the control panel of wind turbines and in its nacelle, in the control panel we use thermal cord of aerosol device and in the nacelle we use this electric start-up of aerosol.
Furthermore, in vehicle engines the electric plus thermal line type aerosol is the best solution, the thermal line can be wrapped around the engine compartment and the another electrical cable is to activate the aerosol by power supply from 3 to 24v battery.
WHAT FEATURES IT HAVE
It is electrical activation only need a small current, and power supply needed is 3 to 24v, 3 to 220v.
It is DIY easy to install in wind turbine and vehicle engine compartment.
Not only total flooding, but also direct-to-source fire protection.
When releasing, it discharge out a white color of aerosol smoke, there are micro aerosol particles to suppress fire at average.
MAIN APPLICATION FIELDS
Computer rooms.
Data processing rooms.
Archives.
Library.
Historic building.
Cable wells.
Underground pipe gallery.
Power generator room and distribution rooms.
Wind turbines.
Various of electrical cabinets and control panels.
FRIENDLY REMINDER
Please read the INSTALLATION MANUAL carefully before install the device.
Do not disassemble the unit without permission.
Better not touch the hot cylinder after its releasing, because in the cylinder after releasing its temperature is super high.
Do not divulge our product structure to others.
HELP INFORMATION WE CAN OFFER
Material Data Sheet.
Catalogue and Brochures, or Fryers.
User Manual.
Product Data and Parameter Sheets
International Certificates and Approvals.
For more details about our aerosol products, you also can inquiry from any of our sales and service people.
