400W 12V 24V 48V Vertical Axis Wind Turbine Alternative Energy Generator Wind Power System
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1993
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Household 400w Small Wind Turbine Generator/12V 24V 48V Wind Turbine Generator/wind Power Generation PriceNegotiableMOQ: 1 -
400W 600W 800W 1000W Horizontal Wind Turbine 12V 24V 48V Alternative Energy Wind Turbine MachineNegotiableMOQ: 1
-
Factory Small Wind Turbines Seek Technical Guidance From Overseas Wind Power Generation AgentsNegotiableMOQ: 1
-
Hot Selling 400W Power Generation Vertical Axis Turbine For Wind Energy Powery SystemsNegotiableMOQ: 1
-
400W China Maglev AC Wind Power System Vertical Axis Wind Generator Turbine for SaleNegotiableMOQ: 1
PRODUCTS DESCRIPTION
400W 12V 24V 48V Vertical Axis Wind Turbine Alternative Energy Generator Wind Power System
◎ Safety The vertical blade is adopted, and the main stress point is concentrated on the hub, so the problems of blade falling off, fracture and blade flying out have been better solved. ◎ Noise Horizontal plane rotation and blade design based on the principle of aircraft wing are adopted to reduce the noise to a level that can not be measured in the natural environment. ◎ Wind resistance The principle of horizontal rotation and vertical flat blade makes it less subject to wind pressure and can resist super typhoon. ◎ Turning radius Because of its different design structure and operation principle, it has smaller turning radius than other forms of wind power generation, saves space and improves efficiency. ◎ Generation curve characteristics The start-up wind speed is lower than that of other types of wind turbines, and the rising range of power generation is relatively gentle. Therefore, within the wind speed range of 5 ~ 8m, its power generation is 10% ~ 30% higher than that of other types of wind turbines. ◎ Utilization wind speed range The special control principle is adopted to expand its suitable operating wind speed range to 2.5 ~ 25m / s, maximize the use of wind resources, obtain greater total power generation, and improve the economy of wind power equipment. ◎ Braking device The blade itself has speed protection and is also equipped with electromagnetic brake. | ||||||||
Model | elege-H1-400W | Number of blades | 3 pieces/5 pieces | ||
Rated power | 400W | Blades material | aluminum alloy | ||
Max power | 2.5KW | Body material | 8A3 carbon steel | ||
Rated voltage | 48V/96V | Generator | three phase AC permanent magnet generator/maglev generator | ||
Start-up wind speed | 2.5m/s | Control System | electromagnetic brake | ||
Rated wind speed | 12m/s | Yaw Mode | automatic windward angle | ||
Survival wind speed | 40m/s | Lubrication mode | self lubrication | ||
Wind wheel diameter | 1.16 m | Tower form | guyed tower/independent tower | ||
Blade Height | 1.8 m | Working temperature | -40℃-80℃ | ||
COMPANY PROFILE
Elege Electronic Technology (Zhangjiagang) Co., Ltd. has over 10 years of experience designing and Solar Energy Products
volumes depending on your needs.
Our manufacturing facilities can build just about many types of Computer Hardware & Software &Solar Energy Products.
Our advantages:
1. Quality control:most of products have CE ROHS, certificate. ISO9001:2008.
2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.
3. Fast Delivery Time :2~15 days, On-Time Delivery.
4. Good After-Sales Service: we could offer technical support or return service in short time.
5. 1 Year Warranty.
6. OEM/ODM service.
7. We are available with Alibaba Trade Assurance, you'll enjoy:
•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount
Certifications
OUR ADVANTAGES
FAQ
• Q: Are you a factory?
A: We have our own electronic equipment, antenna production factory.
• Q: Can I get some samples?
A: Yes, sample order is available for quality inspection and market testing, it will be freight collect.
• Q: What is the lead time?
A: It usually takes about 1-3 days to produce samples.
It usually takes about 3-7 days to produce the product.
• Q: What is your payment term?
A: We usually accept PAYPAL, T/T as the main payment method, other payment methods can also be negotiated.
• Q: Quality problem?
A: If there is any quality problem or question, we can provide technical support or return service.
• Q: How can I contact us?
A: Send your inquiry details below, click "Send"! ! ! Free samples and best answers are waiting for you.
