Product Description




Features:
* LED display.
* Explosion-proof motor.
* Explosion frequency inverter.
* Explosion auto temperature controller.
* Stepless speed controller.
* Auto-lifting bath is optional.
* Stainless steel and aluminium alloy structure.
* Anti-corrosive PTFE sealing with good performance.
Specification
Model
ExRE-1002
ExRE-2002
ExRE-5003
Rotary Bottle
10 L( flange φ95)
20L (flange φ95)
50L (flange φ125)
Collecting Bottle
5L ( flange φ50)
10L (flange φ60)
20L (flange φ60)
Condenser
Vertical three backflow ,φ120*640mm(main),
φ135*470mm(SUB)
Vertica lthree backflow ,φ130*680mm(main),
φ160*530mm(SUB)
Vertical three backflow ,φ160*840mm(main),
φ160*530mm(SUB)
Charging Valve
34#(standard size）
40#(standard size）
Rotating Speed
0~110 rpm
Vacuum
-0.098 Mpa
Temp Range
RT~400℃
Temp. Accuracy
±1℃
Rotating Power
120 W
120 W
180 W
Heating Power
3 KW
5 KW
7/8KW
Power Supply
AC220V±10%, 50 Hz
AC220V±10%, 50 Hz
AC220V±10%, 50 Hz
or 380/50 V/Hz
External Size(W*D*H)
1050*580*1950 mm
1100*600*2100 mm
1300*720*2300 mm
Package Size(W*D*H)
1350*350*400 mm
1280*570*660 mm
1370*700*680 mm
700*680*740 mm
1450*390*440 mm
1150*840*660 mm
790*730*790 mm
Gross Weight
100 Kg
123 Kg
170 Kg
StandardAccessory
10L rotary bottle*1,
5L collecting bottle *1,
20L rotary bottle*1,
10L collecting bottle *1,
50L rotary bottle*1,
20L collecting bottle *1,
Explosion-proof transducer, Explosion-proof motor EX120W
Optional Accessory
Double collection bottle, Auto-lifting, Vacuum pump, Recirculating chiller
Similar products
Packing & Delivery
Standard wooden Packing
Company Profile
BIOBASE was founded in 1997, focusing on development, production and management of laboratory and medical equipment. MEDFUTURE provide one-stop procurement solution which can not only reduce the resourcing cost, but also can ensure good quality and sufficient after-sale service. BIOBASE is specialized in products of 9 areas including laboratory equipment, cleaning and disinfection equipment, laboratory safety protection product, cold chain product, medical equipment, general analytical equipment, measuring equipment, physical test equipment and some industry research equipment. BIOBASE has excellent research team, strong quality control team, professional sales team and responsible after-sale service team, to provide you quality products and good service. BIOBASE also made field trip to many suppliers in China, controlled the product quality strictly instead of customers, as well as strived from the suppliers to get competitive pricing. Recently, BIOBASE has confirmed many OEM partners and will keep searching for more suppliers upon customer' request. BIOBASE would like to establish win-win business cooperation with distributors all over the world.
