Particle Size Analyzer
Product Description
MF-2308C intelligent full automatic wet&dry laser particle size analyzer adopt full
MIE scattering principle, measure size is from 0.01um to 1200um(dry 0.1um-1200um),
Which offer reliable and repeatable particle size analysis for a diverse range of
applications.It use dual-beam& multiple spectral detection systems and side light scatter
test technology to significantly improve precision and performance of test, It’s the prior
choice for industrial production quality control departments and research institutions.
Specification
Model Name
MF-2308C
Principle
Laser scattering principle
Measuring Range
Dry:0.1~1200 micron
Wet:0.01~1200 micron
Channels Number
Dry:80 pcs
Wet:97 pcs
Accuracy Error
<1% (Deviation of D50 on national standard sample)
Repeatability Error
<1% (Deviation of D50 on national standard sample )
Light Source
He-Ne laser P>3.0 mw (λ= 632.8nm) life time>25000hours
Auxiliary semiconductor laser (λ= 532 nm) P＞2.0mw
Wet
Dispersion
Ultrasonic
Frequency: 40KHz
Power: 35w
Time: ≥1s
Agitator
Revolutions Speed: 0~3000rpm (Adjustable)
Circulation
Rated Flow: 8L/min
Rated Power:10w
Sample Tank
Volume: 350ml
Operation Mode
Full automatic
Optical Alignment
Automatic
Data Acquisition Rate
2KHz
Test Speed
Wet: ＜2 Min per time
Dry: <1min per time
Fastest measuring speed:10s
Operation Enviroment
Temperature: 10~40℃
humidity: 0~90%
Outer Dimension(L*W*H)mm
920*440*500
Net Weight
70Kg
