Product Description
BIOBASE
Hematology analyzer
BK-3100
Feature:
1.9.7-inch color touch LCD screen, easy to operate, display all parameters and histograms on the same screen.
2. Fewer samples are required for testing: whole bloodS10μl, pre-diluteds 20μl.
3.60 samples/hour.
4.21 parameters + 3 histograms.
5. It can be turned on continuously for 24 hours.
6. Automatically clean the sampler, counting pool and pipeline after starting up.
7. Built-in thermal printer, external printer can be connected.
8. Electrical impedance method, cyanide-free detection of HGB.
9. Fully itelligent blockage removal and alarm function.
10. Both automatic calibration and manual calibration are available.
11. Counting Mode: Venous, capilary, prediluted.
12. Support LIS system.
Specification
Model |
BK-3100 |
||||||||||
Throughput |
60 samples/hour |
||||||||||
Principle |
Impedance for WBC differentiation and WBC/RBC/PLT count; Colorimetric method for HGB |
||||||||||
Channels |
2 |
||||||||||
Parameters |
21 parameters(including WBC, Mid#, Lym#, Gran#, Mid%, Lym%, Gran%, RBC, HGB, HCT, MCV, MCH, MCHC,RDW-SD, RDW-CV, PLT, MPV,PDW，PCT, P-LCR, P-LCC) |
||||||||||
Histograms |
3 histograms (including WBC, RBC, PLT histograms) |
||||||||||
Sample Volume |
Whole blood: 10μl, Prediluted: 20μl |
||||||||||
Calibration |
Manual, auto calibration |
||||||||||
Counting Modes |
Venous, capilary, prediluted |
||||||||||
Printing Model |
Auto print, manual print |
||||||||||
LIS |
Support Bi-directional LIS |
||||||||||
Language |
Chinese, English, Spanish, French, Russian, Ukrainian |
||||||||||
Reagent |
Diluent 20L, Hemolytic agent 500ml, Probe cleanser: 50ml |
||||||||||
Data Input |
9.7-inch touch screen, mouse, keyboard (optional) |
||||||||||
Output |
Internal printer, support external printer |
||||||||||
Printer paper |
57*30mm |
||||||||||
Interface |
4 USB ports, network port，RS232 serial port. |
||||||||||
Storage |
100,000 results with histogram |
||||||||||
Unclog |
High voltage burn, reverse high-pressure flush |
||||||||||
Work Temperature |
15-30°C |
||||||||||
Power Supply |
100~240 AC, 50/60Hz, 150VA |
||||||||||
Relative Humidity |
30﹪～85﹪ |
||||||||||
Atmospheric Pressure |
70.0kPa-110.0kPa |
||||||||||
Carry-over rate |
Parameter |
WBC |
RBC |
HGB |
PLT |
||||||
CV |
≤ 1.5% |
≤ 1% |
≤ 1% |
≤ 3% |
|||||||
Background |
Parameter |
WBC |
RBC |
HGB |
HCT |
PLT |
|||||
Background |
≤ 0.3×109/L |
≤ 0.03×1012/L |
≤ 1 g/L |
≤ 0.5% |
≤ 10×109/L |
||||||
Linearity |
Parameter |
Measurement range |
CV |
||||||||
WBC |
(0.5~10.00×109)/L (10.10~99.9×109)/L |
(±0.5×109)/L ±5% |
|||||||||
RBC |
(0.05~1.00×1012)/L (1.01~9.99×1012)/L |
(±0.05×1012)/L ±5% |
|||||||||
HGB |
(2~70g)/L (71~300.0g)/L |
(±2.0g)/L ±2% |
|||||||||
PLT |
(10~100×109)/L (101~999×109)/L |
(±10.0×109)/L ±8% |
|||||||||
Precision |
Parameter |
Whole blood (CV) |
Pre-diluted （CV） |
Measurement range |
|||||||
WBC |
≤ 2.0% |
≤ 4.0% |
(4.0-15.0×109)/L |
||||||||
RBC |
≤ 1.6% |
≤ 3.0% |
(3.5-6.0×1012)/L |
||||||||
HGB |
≤ 1.6% |
≤ 3.0% |
(110.0-180.0g)/L |
||||||||
MCV |
≤1.0% |
≤2.0% |
(70.0-120.0)fL |
||||||||
PLT |
≤ 4.0% |
≤8.0% |
(150.0-500.0×109)/L |
||||||||
External Size(W*D*H) |
295*467*418mm |
||||||||||
Packed Size(W*D*H) |
404*564*616mm |
||||||||||
Net weight |
19 KG |
||||||||||
Gross weight |
31KG |
||||||||||
