Biobase 3-part Auto Hematology Analyzer BK-5000 60 Tests /hour for Hospital Use
Touch Screen display
3-part differentiation of WBC
21 parameters + 3 histograms
Throughput: 60 samples per hour
Model |
BK-5000 |
||||
Throughput |
60 tests/hour |
||||
Measuring Principle |
Coulter principle Colorimetry hemoglobin determination |
||||
Parameters |
WBC, LY#, MID#, GR#, LY%, MID%, GR%, RBC, HGB, HCT,MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, P-LCR, P-LCC |
||||
Histograms |
3 Histograms (including WBC, RBC, PLT) |
||||
Sampler Volume |
Predilute 20μl Whole blood 10μl |
||||
Display |
8” color touch screen display |
||||
Intelligent reagent management function |
Reagent information and residual display |
||||
Carryover |
WBC≤1.5% RBC, HGB<1.0% , PLT≤2% |
||||
Printer |
External printer |
||||
Input and output |
1 RS232 , keyboard , Mouse, 4USB, LAN |
||||
Performance |
Parameter |
Linearity range |
Precision (CV%) |
||
WBC(109/L) |
0.0-100.0 |
2.0 (4.0-10.0) |
|||
RBC(1012/L) |
0.00-9.99 |
1.5 (3.50-5.50) |
|||
HGB(g/L) |
0-300 |
1.0 (110-160) |
|||
PLT(109/L) |
0-1000 |
5.0 (100-300) |
|||
Option |
Barcode scanner, LIS |
||||
Operating Environment |
Temperature 10-35 oC Humidity≤90% |
||||
Power Supply |
AC110/220V±10%, 60/50 Hz |
||||
Package Size(mm) |
630*600*700 |
||||
Gross Weight(kg) |
25 |
||||
Reagent Package Size(mm) |
390*280*260 |
||||
Reagent Gross Weight(kg) |
13 |
||||
