Help CenterCL-6670 On-line Lon Controller
Related Products
Applications：
Industrial Online Ion selective meter is a
microprocessor-based water quality online monitoring
control instrument. The instrument is widely used in
industrial waste water, surface water, drinking water,
sea water, and industrial process control ions on-line
automatic testing and analysis, etc.Continuously
monitor and control ,Ion concentration and temperature
of aqueous solution.
Feature：
● LCD display
●Intelligent menu operation
●Data Recording & Trend Display
●Multiple automatic calibration function
●Differential signal measurement mode,stable and reliable
●Manual and automatic temperature compensation
●Three sets of relay control switches
●High & low alarm and hysteresis control
●4-20mA&RS485 Multiple output modes
●Multi parameter display Simultaneously shows - pH,Temp, mV,etc.
●With password protection to prevent misoperationby non-staff.
Measuring range:Ion concentration: 0～99999mg/L；Temperature: -5～150.0℃；
Resolution:Ion concentration: 0.01mg/L；Temperature: 0.1℃；
Basic error:Ion concentration:（Including electrode）：Reading: ±2.5%；
Temperature: ±0.3℃；Two Current output:0/4~20mA(load resistance<750Ω);20~4mA(load resistance<750Ω);
Communication output: RS485 MODBUS RTU；
Three relay control contacts: 5A 250VAC，5A 30VDC；
Power supply(optional):85～265VAC±10%,50±1Hz，Power :≤3W；9～36VDC，Power : ≤3W；
Overall dimension: 144×144×118mm；
Installation mode: panel, wall hanging, pipe type;
Panel opening size：138×138mm；
Waterproof grade： IP65；
Instrument weight： 0.8kg；
Instrument working environment：Environment temperature ：-10～60℃；Relative humidity：≦90%；
In addition to the earth's magnetic field aroundno strong magnetic interference
