Dock Fixed Large Unloading Crane
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
1998
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New Hydraulic Crawler Crane Lifting Machine 16 Ton Truck Crane PriceNegotiableMOQ: 1 -
Rough Terrane Crane Mobile Crane 10 Ton 12 Ton 16t Ton Truck Mounted Crane Hot Sale In UAENegotiableMOQ: 1
-
Pick Up Truck Crane Diesels 4x4 Manual Crane For TransportNegotiableMOQ: 1
-
16 Ton Telescopic Boom Ship Crane Folding Boom CraneNegotiableMOQ: 1
-
Ship Crane Fixed Hydraulic Telescopic Boom Port Terminal Crane Sitting CraneNegotiableMOQ: 1
Product Description
Dock fixed large unloading crane
Our truck mounted cranes, articulating/knuckleboom cranes and hydraulic loaders help you accomplish more on your job sites. Whether your crane truck will be working on a construction site, in a mine, moving materials, assisting with utility maintenance, handling tires or transporting heavy equipment, our truck mounted crane team can specify and customize a truck to successfully accomplish the unique challenges you face.
Specification
Model |
HW-63TCB |
Span (mm) |
4800/5500/5700 |
||
Choose chassis |
Dongfeng |
Engine model |
YC6JA180-50 |
||
Emission Standards |
National V emission standards |
Engine power |
132KW |
||
Maximum lifting weight （T） |
6.3 |
Tyre model |
10.00R20 |
||
Boom （M） |
12.5 |
Wheelbase (mm) |
5100 |
||
Basic arm length （M） |
4 |
Dimensions (mm) |
9000*2400*3850 |
||
Maximum lifting height （M） |
15.3 |
Internal dimensions of cargo box (mm) |
5600*2300*550 |
||
Number of boom sections |
4 |
Total weight(kg) |
3225 |
||
Maximum elevation angle |
80° |
Rated load weight (kg) |
5805 |
||
Turn around angle |
0-360 |
Curb weight (kg) |
12380 |
||
Swing speed |
0-3 |
Top speed (km/h) |
90 |
||
Hydraulic outrigger |
Automatic |
Out arm way |
Cylinder + rod rope |
||
Big frame |
Three layers |
Steering method |
Hydraulic boost |
||
Product Details
Application
Related Products
Company Profile
Shandong Hengwang Group Co., LTD. Is located in Shiqiao Industrial Park, Beihu Provincial Tourist & Resort Area, Jining city ,Shandong Province,covers an area of 40000 square meters, is a collection of pile driving machinery ,water well driling machine and conctruction machinery design, manufacture and installation of an integrated enterprise.
Our company produces the piling machinery a total of 10 major series more than 20 varieties, mainly include photovoltaic crawler pile driver, caterpillar screw drivers, HW series, KLB hydraulic pile driver walking long spiral drill, caterpillar diesel pile hammer machine, vibration sinking pipe pile, DZB multi-function rig, water well driling rig machine,concrete pump and other products. Widely used in civil engineering, municipal and building foundation construction of installation works. Can meet the roads, railways, Bridges, industrial and civil building, harbor wharf, the need for the basic construction of the dam seepage control and so on.
