2022 Evangel China Official Manufacturer 2M SHANTUI Cold Milling Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2022 Evangel China Famous Brand Shantui Cold Milling Machine With Milling Depth 2MNegotiableMOQ: 1 -
2022 Evangel SHANTUI Head Rotary Table 2m Width Cold Milling MachineNegotiableMOQ: 1
-
2022 Evangel China Brands SHANTUI SM200M-3 Cold Milling Machine PriceNegotiableMOQ: 1
-
2022 Evangel SHANTUI Top Brand SM200M-3 Large Cold Milling Machine With Spare PartsNegotiableMOQ: 1
-
2022 Evangel Rubber Track Shoe Cold Milling Machine Shantui SM100MT-3NegotiableMOQ: 1
China Official Manufacturer 2M SHANTUI Cold Milling Machine
Contact way:
Contact Way
Annie Li
Mobile / Whatsapp / Wechat: +86138 1769 0558
Evangel(shanghai)Industrial Co,Ltd
Evangel International Machinery Ltd
Add: Suite 2806, Super Ocean Finance Center,
No. 2067 West Yan'an Road, Shanghai, China
Web:
Product Description
ENGINE POWER
With 447kW/2100rpm, this engine conforms to Euro-ⅢA emission regulation.
OVERALL WEIGHT
29700kg
MILLING WIDTH
2000mm
Drive system
- The 600ps electronic injection engine works with 32t operating weight to realize high milling capability and high efficiency for hard roads and large-depth milling.
- The energy-saving technologies, including temperature controlled fan technology and engine automatic idling technology, realize better fuel economy of the machine.
- The limit load function guarantees the engine against flameout under severe working condition.
- The milling drum is driven by mechanical belt and the drive belt is hydraulically tensioned, featuring high drive efficiency, effectively mitigated operating impact, and stable and reliable power transmission.
Easy maintenances
- The structural parts inherit the excellent quality of Shantui’s mature products.
- The large opening design for engine hood and side doors provides a spacious room for maintenances.
- The core electric and hydraulic parts adopt imported products, featuring stable and reliable quality and extremely high reliability.
- The external fuel/oil filter and grease nozzles are installed in hanging manner to ease the maintenances and replacement.
| Parameter name | SM200M-3 (Standard version) |
| Performance parameters | |
| Operating weight (Kg) | 32000 |
| Transport weight(Kg) | 29700 |
| Maximum milling width (mm) | 2000 |
| Maximum milling depth (mm) | 320 |
| Engine | |
| Engine model | QSX15 |
| Rated power/rated speed (kW/rpm) | 447/2100 |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 14940*2515*4090 |
| Driving performance | |
| Traveling speed (km/h) | 0-5 |
| Working speed (m/min) | 0-83 |
| Conveyor System | |
| Width of conveyor belt (mm) | 800 |
| Swing angle of conveyer (Rightward/leftward) (°) | ±45 |
| Tank capacity | |
| Fuel tank (L) | 1120 |
| Working device | |
| Number of milling cutters (Piece) | 162 |
Detailed Images:
