10 Ton Single Drum Roller SSR100AC-8 With Sheep Foot
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Blade 14FT 230HP Motor Grader STG230C-8 With Rear Ripper
-
Blade 12FT 210HP Motor Grader STG210C-8 With Rear Ripper
-
Blade 12FT Rear Ripper Small Motor Grader STG190C-8
-
Blade 12ft Small Motor Grader STG170C-8 With Rear Ripper
-
12FT Blade Small Motor Grader STG140C-8 With Rear Ripper
-
XS203 Full Hydraulic Good Quality 20t Single Drum Road Roller for Sale
Product Description
10 Ton Single Drum Roller SSR100AC-8 with Sheep Foot
Contact
Alivior Liu
Sales Director
Skype:liying.liu3
Wechat:2806003380
Mobile,Whatsapp: +86-156-0190-8606
Features
High Efficiency
10% greater excitation force than other products in the same category resulting in 16.7% greater production.
Extended Life Time
The use of water wheel type lubrication on the vibratory bearing extends the bearing life up to 5,000 hours.
The engine air filter is raised and the air is filtered twice to protect the engine.
The hydraulic system contains three stage filtration.
Operator Comfort
Cab mounted on vibration damping mounts
Cab temperature control
Operator control forces have been reduced
Safety Features
Rounded bumpers front and rear
Large rear glass and sloped hood for greater visibility
Parameters
| Type | SSR100AC-8 | SSR120AC-8 | SSR200AC-8H | SSR220AC-8H | SSR260AC-8H |
| Dimensions | 5575*2285*3225 | 5755*2285*3225 | 6620*2270*3330 | 6620*2270*3330 | 6500*2380*3300 |
| Compaction Mechanism | |||||
| Drum Width | 2130mm | 2130mm | 2130mm | 2130mm | 2170mm |
| Excitation Force | 246/124kN | 280/178kN | 368/258kN | 390/258kN | 416/295kN |
| Nominal Amplitude | 2.0/1.0mm | 1.8/0.9mm | 1.9/0.95mm | 1.9/0.95mm | 1.9/0.95mm |
| Vibration Frequency | 30/30Hz | 32/36Hz | 29/35Hz | 29/35Hz | 27/32Hz |
| Drum Static Linear Load | 268N/cm | 282N/cm | 470N/cm | 516N/cm | 610N/cm |
| Engine | |||||
| Emission | - | - | CHINA Ⅲ | CHINA Ⅲ | CHINA Ⅲ |
| Engine Model | 4BTAA3.9-C125 | 4BTAA3.9-C125 | WP6G200E331 | WP6G200E331 | WP6G200E331 |
| Rated Power | 93kW | 93kW | 147kW | 147kW | 147kW |
| Maneuver Ability | |||||
| Theoretical Gradeability Vibratory | 40% | 40% | 30% | 30% | 30% |
| Travel Speed | 0~9km/h | 0~9km/h | 0~8km/h | 0~8km/h | 0~8km/h |
| Ground Clearance | 480mm | 480mm | 440mm | 440mm | 440mm |
| Weight and Load | |||||
| Operating Weight | 10T | 12T | 20T | 22T | 26T |
| Weight at Drum | 5T | 6T | 10T | 11T | 13T |
| Weight at Rear Axle | 5T | 6T | 10T | 11T | |
Pictures
