20 Ton Road Roller Single Drum Full Hydraulic System Compactor XS203
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Road Paver 13m Asphalt Concrete Paver SSP125C-8NegotiableMOQ: 1 -
Road Paver 10m Asphalt Concrete Paver SSP100C-8NegotiableMOQ: 1
-
Road Paver 8m Asphalt Concrete Paver SSP80C-8NegotiableMOQ: 1
-
Road Paver 12m Asphalt Concrete Paver SAP120C-8NegotiableMOQ: 1
-
Road Paver 9.2m Asphalt Concrete Paver SAP90C-8NegotiableMOQ: 1
20 ton road roller single drum full hydraulic system compactor XS203
Product Description
| Type | Unit | XS203 |
| Operating weight | kg | 20000 |
| Load applied on front drum | kg | 13500 |
| Load applied on rear wheels | kg | 6500 |
| Compacting width | mm | 2130 |
| Static linear load | N/cm | 621 |
| Vibration frequency(Low/High) | Hz | 28/33 |
| Nominal amplitude(High/Low) | mm | 1.86/0.93 |
| Exiting force(High/Low) | KN | 370/255 |
| Travel speed | km/h | 0~10 |
| Steering angle | ° | ±33 |
| Swing angle | ° | ±10 |
| Theoretical gradeability | % | 50 |
| Min. external turning radius | mm | 6500 |
| Engine model | DEU-TZ BF6M2012C | |
| Engine power | kw | 136 |
| Rated engine speed | r/min | 2200 |
| Engine oil consumption | g/kW.h | 222 |
| Hydraulic oil tank capacity | L | 240 |
| Fuel tank capacity | L | 240 |
