Cheap Price ZOOMLION 110 Ton Truck Crane ZTC1100
Feasures
A truck crane featuring full circle swinging, telescopic luffing jib and five-section boom subject to hydraulic proportional control;
• Four-axle dedicated chassis, broad vision, simple and generous decorations, 8×4 drive;
• It adopts the latest directional valve and quadruple gear pump system, with such safety devices as overflow valve, balance valve, hydraulic lock and brake valve equipped to prevent oilway overload and avoid accidents due to pipe fracture, ensure that all actuators could give full play to their working ability, and improve the system reliability and safety;
• Such safety devices as torque limiter and complete lighting system are equipped to ensure safe and reliable operation, and facilitate operation at night;
• The complete crane features an innovative design, with its body, line and tint beauty integrated.
Parameters
|
Item |
Value |
Remarks |
|
|
Working performance |
Max. rated lifting capacity kg |
110000 |
|
|
Max. load moment of basic boom kN.m |
3540 |
||
|
Max. load moment of max. length main boom kN.m |
1728 |
||
|
Max. lifting height of basic boom m |
13.7 |
||
|
Max. lifting height of main boom m |
59.2 |
These parameters do not include deflection of main boom and jib. |
|
|
Max. lifting height of jib m |
86.0 |
||
|
Working speeds |
Max. hoist rope speed (Main winch) m/min |
≤130 |
Drum 4th layer |
|
Max. hoist rope speed (Auxiliary winch) m/min |
≤110 |
Drum 2nd layer |
|
|
Boom derricking up time s |
60 |
||
|
Boom telescoping out time s |
480 |
||
|
Slewing speed r/min |
0 - 1.6 |
||
|
Max. driving speed km/h |
90 |
||
|
Max. gradeability % |
40 |
||
|
Min. turning diameter m |
23 |
||
|
Min. ground clearance mm |
310 |
||
|
Oil consumption per hundred kilometer L |
46 |
||
|
Mass |
Deadweight in driving condition kg |
50000 |
|
|
Complete vehicle kerb mass kg |
49805 |
||
|
Front axle load kg |
24000 |
||
|
Rear axle load kg |
26000 |
||
|
Dimensions |
Overall dimensions (L × W × H) mm |
15000×2850×3820 |
|
|
Outrigger spread (L) m |
6.38 |
||
|
Outrigger spread (W) m |
Fully extended: 8.0 m Intermediately extended: 5.3 m |
||
|
Tail slewing radius mm |
4420 |
||
|
Main boom length m |
12.5-58.5 |
||
|
Boom angle ° |
-2 – 80 |
||
|
Jib length m |
10.4, 17.5 |
||
|
Jib offset ° |
0, 15, 30 |
||
|
Extension length m |
9.5 |
Optional |
|
|
Extension offset ° |
0 |
||
|
Tip boom length m |
3 |
Optional |
|
|
Tip boom offset ° |
30 |
||
