2022 Evangel 2022 Evangel Zoomlion 25t Zoomlion 25 Ton Crane Zoomlion Hydraulic Arm Crane For Trucks Ztc250V4 ZTC250R
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2022 Evangel Zoomlion 25t Price Hydraulic Dump Truck With Crane Lifting For Truck ZTC250RNegotiableMOQ: 1 -
2022 Evangel Zoomlion 25t Truck Crane 25Tons Full Extended Zoomlion Tata Truck Crane 45M Boom ZTC250RNegotiableMOQ: 1
-
2022 Evangel Zoomlion 25t High Performance Xct80 80 Ton Truck Crane In Bangladesh For Sale ZTC250RNegotiableMOQ: 1
-
2022 Evangel Zoomlion 25t Factory Price Truck With Crane 70 Ton Lifting Capacity ZTC250RNegotiableMOQ: 1
-
2022 Evangel Zoomlion 25t 25Tons Hydraulic Mobile Truck Crane With Pilot Control ZTC250RNegotiableMOQ: 1
ZOOMLION 25ton mobile truck crane for sale
Product Description
-
-
-
-
New generation 4.0 series platform 55T with 5 section main boom(11.2m-44m).
-
Max. lifting moment reaches to 1568kN.m, max. lifting height with jib up to 60m.
-
Standard tiltable operator's cab.
-
High ROI.
-
-
-
Parameter
| Item | Unit | Value | Remarks | |
|---|---|---|---|---|
| Working performance | Max. rated lifting capacity | kg | 25000 | |
| Max. load moment of basic boom | kN.m | 960 | ||
| Max. load moment of main boom(fully extended) | kN.m | 598 | ||
| Max. load moment of basic boom | m | 10.9 | ||
| Max. lifting height of main boom | m | 40.2 | These parameters do not include deflection of main boom and jib | |
| Max. lifting height of jib | m | 47.8 | ||
| Working speeds | Max. hoist rope speed(Main winch) | m/min | 135 | At the 4th layer |
| Max. hoist rope speed(Auxiliary winch) | m/min | 135 | At the 4nd layer | |
| Boom demrricking up time | s | 25 | ||
| Boom telescoping out time | s | 82 | ||
| Slewing speed | r/min | 0 -2.7 | ||
| Driving parameters | Max. driving speed | km/h | 85 | |
| Max. gradeability | % | 42 | ||
| Turning diameter | m | ≤20 | ||
| Min. ground clearance | mm | 250 | ||
| Oil consumption per hundred kilometers | L | 28 | ||
| Mass | Deadweight in driving condition | kg | 30600 | |
| Complete vehicle kerb mass | kg | 30470 | ||
| Front axle load | kg | 6500 | ||
| Rear axle load | kg | 24100 | ||
| Dimensions | Overall dimensions(L×W×H) | mm | 12600×2500×3450 | |
| Outrigger spread(L) | m | 5.40 | ||
| Outrigger spread(W) | m | Fully extended:6.2, Intermediately extended:4.25 |
||
| Tail slewing radius | mm | 3265 | ||
| Main boom length | m | 10.2 - 40.0 | ||
| Boom angle | ° | -1 - 80 | ||
| jib length | m | 8.0 | ||
| Offset | ° | 5,17,30 |
Photo for reference
