Hot Sale New 30 ton Truck Crane STC300T5/QY30K5C/STC300E
QY30K5C
1. With all covered walking surface, anti-torsion box structure and optimal load-bearing structure design, made of imported high strength steel.
2. SC9DF300.1Q5, in-line six-cylinder water-cooled EFI diesel engine, rated power 221kW /2200rpm, max. torque 1250Nm / 1400rpm, the national V emissionstandards. Fueltank capacity:320L
3. FA-ST manually mechanical control,9-speedavailable,synchronizer is equipped.
| Description | Unit | Parameter value | |
| Overall length | mm | 12850 | |
| Overall width | mm | 2550 | |
| Overall Height | mm | 3480 | |
| Wheel Base | mm | 4500+1350 | |
| Track | mm | 2059/2074/1834 | |
| Total vehicle mass in travel configuration | kg | 33000 | |
| Axle load | 1st axle | kg | 7400 |
| 2nd axle | 12800 | ||
| Engine Model | SC9DF300.1Q5 | ||
| Engine rated power | kw/(r/min) | 221/2200 | |
| Engine rated torque | N.m/(r/min) | 1250/1400 | |
| Max. travel speed | km/h | ≥90 | |
| Min. turning diameter | m | ≤21 | |
| Min. ground clearance | mm | 250 | |
| Max. grade ability | % | ≥40 | |
| Approach angle | ° | 11 | |
| Departure angle | ° | 13.5 | |
| Braking distance (at 30 km/h, full load ) | m | ≤10 | |
STC300T5
COMPACT DESIGN
The three-axle cranes are capable of accessing various urban or small jobsites, featuring high flexibility and fast transferring.
PRECISION & ECONOMY
Valves and other hydraulic components realize better inching motion performance. Load-sensing and constant-power techniques optimize fuel efficiency.
Max Lifting Capacity 30T
Max Lifting Height 51m
Max Lifting Moment 1158kN·m
Max Boom Length 42.5m
Max Jib Length 8m
Full Counterweight 5.9T
Engine Model (Emission Standard) DF Cu-m-mins ISLe290 30 (Euro 3)
Max Traveling Speed 90km/h
Wheel Formula 6 × 4
Max Gradeability 42%
Available Districts LHD & RHD countries
