new 50 ton crane price in india for sale QY50KD

Name: new 50 ton crane price in india for sale QY50KD
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Contact Way

Annie Li

Sales Manager

Wechat/Mobile/Whatsapp: +86 138 1769 0558

Email: Annie at

Products Description

Feature:
Highlight 1: Leading lifting and driving performances
1. Five section U-type booms. The boom length is 11.4m-43.5m with strong lifting performance, leading 5%-10% ahead of products with the same tonnages in the same industry.
2. High-power engine with good dynamic performance, strong gradeability and superior trafficability. The maximum gradeability and maximum travel speed respectively are 42% and 85km/h.

Highlight 2: Reliability of heat dissipation, electrical system etc. has been improved with safer operation and driving
1. Waterproof connector clip. It is equipped with rubber sheath inside with excellent water impervious and level of protection reaches to IP65.
2. Aluminium alloy fuel tank. Good appearance quality, corrosion resistance, strong shock resistance capacity.
3. Double- broken line winch. The hoisting rope is in alignment, and it will be more reliable if turn off the press-rope machine.
4. Optimized heat-removal system. The air-conditioning condenser is separately installed, the heat-sinking capability is sharply improved and the environment temperature reached to more than 45℃.

Highlight 3: Mature and reliable double-pump confluence technique, maintaining the advantages of efficient operation
Special confluence multi-valve has been designed. The double-pump confluence technique is adopted in raising and falling of winch, extending and retracting of lazy boom and luffing, leading ahead of luffing and extending and retracting operations.

Highlight 4: Air-aid shift gears and 45% of shifting force is reduced
Special air-aid shift gears protection mechanism. The boost system will work only by stepping on the clutch that effectively
avoids gearbox damaging gears when shifting. Compared with the same industry, 100mm distance of shift gears and 45% of shifting force are respectively reduced.

Highlight 5: Appearance molding is newly upgraded, humanized design and comfortable riding manipulation
New operating house, wheel house, engine hood and machine shed, novel appearances, fine lines of the complete machine appearance, shows its elegant appearance.

The rearview mirror is installed in operating house, easy to for observe the working environment; front pedal and push-and-pull pedal in left side are installed, easy access to the operating house; Ladder stand is installed in two sides of the chassis, easy to get on or off the bus. In addition, tool cabinet is installed in right rear side of the frame, easy to store tools attachment for users, fully representing the purpose of humanized design.

Product Paramenters

Description			Unit	Parameter value
Overall length			mm	13930
Overall width			mm	2780
Overall Height			mm	3630
Axle base	1st ,2nd axle	mm	1470
			2nd ,3rd axle		4300
			3rd ,4th axle		1350
Wheel Base			mm	2304+2075
Front overhang/rear overhang			mm	2389/2064or 2376/2064
Front extension/rear extension			mm	2131/226 or 2144/226
Total vehicle mass in travel configuration			kg	42200
Axle load	Front axle	kg	16200
Axle load		kg	Rear axle		26000
Engine Model				WD615.338
Engine rated power			kw/(r/min)	276/2200
Engine rated torque			N.m/(r/min)	1500/1300-1600
Max. travel speed			km/h	85
Min. steady travel speed			km/h	2~3
Min. turning diameter			m	24
Min. ground clearance			mm	327
Max. grade ability			%	42
Approach angle			°	19
Departure angle			°	15
Braking distance (at 30 km/h, full load )			m	≤10
Oil consumption per 100km			L	40
Exterior noise level during acceleration traveling			dB (A)	≤88
Noise level at seated position			dB (A)	≤90
