Products Description
70 ton truck mounted crane 70t truck crane price QY70KH
Highlight I: high-power air-conditioner meets the requirements of T3 working condition
High-power air-conditioners are equipped in driver’ s cab and operator’ s cab, heat transferring area of condenser is increased by 75%, displacement of compressor is increased by 20%, refrigeration effect is improved by above 25% relative to regular products, which meets the requirements of T3 working condition.
Highlight II: hydraulic heat radiation system with superpower, permissible ambient temperature exceeds 55℃
The layout mode of oil port of radiator is optimized, heat radiating area of core is increased by 50%, radiation power of
hydraulic oil radiator is improved from 10kW to 18kW, permissible ambient temperature exceeds 55℃, which meets the requirements for high temperature operation.
Highlight III: high-temperature resistant and ageing resistant wiring harness, service life covers product lifecycle
The protecting ply of wiring harness is produced according to QC/T29106-2004 Technical Conditions of Automobile Low-voltage Wiring Harness, heat-resistant temperature is increased to 105℃, corrugated pipes are added for protection, protection class of plug-ins is IP67. The service life in high temperature operation exceeds 15 years.
Highlight I: high-power air-conditioner meets the requirements of T3 working condition
High-power air-conditioners are equipped in driver’ s cab and operator’ s cab, heat transferring area of condenser is increased by 75%, displacement of compressor is increased by 20%, refrigeration effect is improved by above 25% relative to regular products, which meets the requirements of T3 working condition.
Highlight II: hydraulic heat radiation system with superpower, permissible ambient temperature exceeds 55℃
The layout mode of oil port of radiator is optimized, heat radiating area of core is increased by 50%, radiation power of
hydraulic oil radiator is improved from 10kW to 18kW, permissible ambient temperature exceeds 55℃, which meets the requirements for high temperature operation.
Highlight III: high-temperature resistant and ageing resistant wiring harness, service life covers product lifecycle
The protecting ply of wiring harness is produced according to QC/T29106-2004 Technical Conditions of Automobile Low-voltage Wiring Harness, heat-resistant temperature is increased to 105℃, corrugated pipes are added for protection, protection class of plug-ins is IP67. The service life in high temperature operation exceeds 15 years.
Product Paramenters
Overall length |
mm |
13930 |
Overall width |
mm |
2800 |
Overall height |
mm |
3575 |
Total weight in travel |
kg |
43000(without 1t vice counterweight) |
Front axle load |
kg |
17000 |
Rear axle load |
kg |
26000 |
Engine model |
WD615.338(domestic III) |
|
Engine rated power |
kW/(r/min) |
276/2200 |
Engine rated torque |
N.m/(r/min) |
1500/1400 |
Max. travel speed |
km/h |
80 |
Min. turning diameter |
m |
24 |
Min. ground clearance |
mm |
327 |
Approach angle |
° |
19 |
Departure angle |
° |
13 |
Max. grade ability |
% |
40 |
Fuel consumption for 100km |
L |
45 |
