Most Popular LONKING 5 Ton Wheel Loader LG855N With Pilot Control
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China 30ton Heavy Mining Hydraulic Crawler Excavator XE305D With QSB7 Engine for Sale PriceNegotiableMOQ: 1 -
China Mini Small Tyre/track Skid Steer Loader HY280/HY380/HY380C for SaleNegotiableMOQ: 1
-
China Hot Sale 7 Ton Wheel Excavator With Cheap Price LX75NegotiableMOQ: 1
-
Small Coal Mine Explosionproof Electric Hydraulic Bucket Excavator MWY6/0.2 With Breaker Hammer Quick Coupling PriceNegotiableMOQ: 1
-
2022 Evangel Good Price 162kw Engine Power Shantui 5T Wheel Loader SL50WNNegotiableMOQ: 1
Most Popular LONKING 5 ton Wheel Loader LG855N with Pilot Control
Product Description
| Product name | longong high quality 5ton 3cbm industrial chinese wheel loader LG855N | ||
| NO. | DESCRIPTION | UNIT | DIMENSIONS |
| A | Overall Height – Bucket Raised | mm | 5275 |
| B | Bucket Pin Height at Max. Lift | mm | 4119 |
| C | Dump Clearance at Max. Lift ( 45°) | mm | 3062 |
| D | Reach at Max. Lift and 45° Dump | mm | 1276 |
| E | Rack Back Angle at Carry | ° | 48 |
| F | Rack Back Angle at Ground | ° | 45 |
| G | Digging Depth | mm | 50 |
| H | Rack Back Angle at Max. Lift | ° | 53 |
| I | Dump Angle at Max. Lift | ° | 45 |
| J | Carry Height | mm | 400 |
| K | Ground Clearance | mm | 409 |
| L | Center Line of Front Axle to Hitch | mm | 1615 |
| M | Wheel Base | mm | 3230 |
| N | Overall Length | mm | 8015 |
| O | Departure Angle | ° | 32 |
| P | Height to Top of Cab | mm | 3380 |
| Q | Overall Width over Bucket | mm | 3000 |
| R | Min. Turning Radius over Bucket | mm | 7170 |
| S | Min. Turning Radius over Tires | mm | 6537.5 |
