Product Description
ZOOMLION small 7500kg hydraulic crawler excavator ZE75E-10 with breaker price
External structure
Aurora-green coloring,always catch your eyes
Renewal and upgrade Aurora-green painting,360°surrounded windowpanes and streamlined covering profiling create an eye-catching visual impact.
Reinforced Boom
The strengthened and thickened key stress points of Boom can make the Boom withstand the tremendous pressure brought by the construction effortlessly.
Low-resistance and large- capacity bucket
In order to find the best cutting angle of the bucket in the excavation process, we conducted many excavation simulations and developed the D-ARCS low-resistance and large- capacity bucket to further improve the bucket life and comprehensive fuel consumption.
Reinforced track rollers
Innovation in the design of track rollers for 7t class small excavators has greatly increased the stability of products.
Internal structure
Comfort, just enjoy it!
Suspension seat; 5.7 inch large screen display with new man-machine interactive operating system and rich functions, is simple and easy to use; CAN bus radio, USB, Blue-tooth and other entertainment functions are all equipped. At the same time, all-round information management is achieved through the mobile phone software: Can remotely view the fuel consumption, workload, working time statistics, fault alarm, maintenance prompt etc; track and locate the running of the machine.
Flexible and delicate, energy-saving and efficient
With customized load-sense system, the fuel consumption rate is lowered, the operation efficiency and fuel efficiency have been significantly improved. Besides, the three work modes can be matched optimizedly according to working conditions, which improves the operation efficiency and saves energy at the same time.
Main Pump
Customized hydraulic system reduces fuel consumption by 3% and increases efficiency by 8%.
Engine
46.3kW engine, with strong and abundant power, meets the China stageIII emission standard.
Bulldozing blade
Equipped with wear-resistant and strong bulldozing blade, the small excavator can push away bigger obstacles and make construction more convenient.
Items |
Unit |
Value |
|
Model |
Operating mass |
kg |
7500 |
Standard bucket capacity |
m3 |
0.3 |
|
Performance |
Swing speed |
r/min |
11 |
Travel speed (high / low) |
km/h |
2.9/4.8 |
|
Maximum drawbar pull |
kN |
64.3 |
|
Bucket digging force(ISO) |
kN |
56 |
|
Arm digging force(ISO) |
kN |
38 |
|
Engine |
Engine manufacturer |
- |
Yan-mar |
Rated power |
kw/rpm |
46.3/2200 |
|
Displacement |
L |
3.3 |
|
Emission |
- |
China stage3 |
|
Dimensions |
Total length |
mm |
6149 |
Total width |
mm |
2346 |
|
Total height |
mm |
2650 |
|
Tail swing radius |
mm |
1775 |
|
Track gauge |
mm |
1750 |
|
Track length on ground |
mm |
2200 |
|
Work range |
Max. digging reach |
mm |
6270 |
Max. digging reach at ground level |
mm |
6119 |
|
Max. digging depth |
mm |
4046 |
|
Max. digging height |
mm |
7003 |
|
Max. dumping height |
mm |
5128 |
