Home > Products > Earthmoving Machinery > Shantui Bull Dozer Mini Tractor Crawler Bulldozer Dozer 160HP Bulldozers With Best Price for Sale SD16
Shantui Bull Dozer Mini Tractor Crawler Bulldozer Dozer 160HP Bulldozers With Best Price for Sale SD16
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Hot Sale Shantui SE150 15 Ton Hydraulic Hammer Crawler Excavator Price in Bangladesh
-
SHANTUI 13.5 Ton Long Arm Crawler Excavator SE135W Excavator Drilling Rig
-
Official Excavating Machinery 8 Ton Hydraulic Mini Excavator SE75 SE80
-
Mini Excavator Crawler 3.5 Ton 0.1 Cbm With Spare Parts LOWEST Price SE35 China ShanTui
-
Manufacturers Sell High 2 Ton China Mini Crawler SE23 Small Excavator Digger Wildly Used
-
Straight Tilt Blade 130HP SHANTUI Swamp Bulldozer SD13S
Product Description

Products Description
Weichai WD10G178E25 features the advantages of robust power, easy maintenance, and high combustion efficiency and conformed to China-II emission regulation.
The planetary power shift transmission with forced lubrication and the hydraulically assisted steering system achieve light
operations of the machine and feature high transmission power and high productivity.
The closed system maintains the water tank pressure at specific value and can improve the evaporation temperature and heat dissipation efficiency of coolant.
The fan is driven by the engine to enhance the cooling effect with forced air supply.
The mainstream 14MPa working hydraulic system is adopted to remarkably reduce the malfunction rate of hydraulic units, featuring high operation stability and overload protection function.
The application of water-proof connectors, new relays, and injection molded instruments can effectively eliminate the electric system malfunctions. The instrument box integrates the A/C, electric devices, and instruments, featuring beautiful appearance and high grade.
The full box-type main frame adopts full box-type integral structure welded from steel plates and is welded together with the real axle housing to realize high carrying capacity against impact load and bending moment and the high quality welds guarantee the life cycle of the main frame.
The swing type balance beam suspension structure with splayed beam is connected with the frame and traveling system to transmit the working load and impact load to the main frame during working, which effectively improves the stability of small-sized bulldozers under complicated working conditions.
The standard straight tilting blade features powerful cutting force and the three-shank ripper can be use for the ripping of clay and frozen earth, featuring high working efficiency and super-strong penetrating force.
The planetary power shift transmission with forced lubrication and the hydraulically assisted steering system achieve light
operations of the machine and feature high transmission power and high productivity.
The closed system maintains the water tank pressure at specific value and can improve the evaporation temperature and heat dissipation efficiency of coolant.
The fan is driven by the engine to enhance the cooling effect with forced air supply.
The mainstream 14MPa working hydraulic system is adopted to remarkably reduce the malfunction rate of hydraulic units, featuring high operation stability and overload protection function.
The application of water-proof connectors, new relays, and injection molded instruments can effectively eliminate the electric system malfunctions. The instrument box integrates the A/C, electric devices, and instruments, featuring beautiful appearance and high grade.
The full box-type main frame adopts full box-type integral structure welded from steel plates and is welded together with the real axle housing to realize high carrying capacity against impact load and bending moment and the high quality welds guarantee the life cycle of the main frame.
The swing type balance beam suspension structure with splayed beam is connected with the frame and traveling system to transmit the working load and impact load to the main frame during working, which effectively improves the stability of small-sized bulldozers under complicated working conditions.
The standard straight tilting blade features powerful cutting force and the three-shank ripper can be use for the ripping of clay and frozen earth, featuring high working efficiency and super-strong penetrating force.
Specification
L×W×H (Ripper not included) | mm | 5140×3388×3032 | ||
Operating weight (Ripper not included) | t | 17 | ||
Engine | - | Shangchai SC11CB184G2B1/ Weichai WD10G178E25 | ||
Rated power | kW/rpm | 120/1850 | ||
Gradeability | ° | 30 | ||
Blade type | - | Straight tilt blade U blade Angle blade | ||
Blade width | mm | Straight tilt blade 3388×1149 U blade 3556×1120 Angle blade 3970×1040 | ||
Dozing capacity | m3 | Straight tilt blade 4.5 U blade 5 Angle blade 4.3 | ||
Ma× drop below ground of blade | mm | 540 | ||
Lift height of blade | mm | 1095 | ||
Ripper type | - | Three-shank ripper | ||
Ripping depth of ripper | mm | 572 | ||
Lifting height of ripper | mm | 592 | ||
Number of carriers (each side) | - | 2 | ||
Number of track rollers (each side) | - | 6 | ||
Number of track shoes (each side) | - | 37 | ||
Width of track shoe | mm | 510 | ||
Track gauge | mm | 1880 | ||
Ground length and ground pressure | mm/MPa | 2430-0.067 | ||
Pitch | mm | 203.2 | ||
Forward speed | km/h | 0–3.29 | ||
0–5.82 | ||||
0–9.63 | ||||
Reverse speed | km/h | 0–4.28 | ||
0–7.59 | ||||
0–12.53 |
