Product Description
Products Description
Pay Loader 5 Ton Front Loader Small Wheel Loader LW500KN
Heavy load for the rocky condition; the working device and front and rear frame feature thick board of high strength, reasonable distribution and strong carrying capacity.
The large rock bucket with capacity of 3.0M3 is improved in terms of the work efficiency and adaptation. The bucket teeth adopt the structure of toothholder and sleeve. The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.
The large rock bucket with capacity of 3.0M3 is improved in terms of the work efficiency and adaptation. The bucket teeth adopt the structure of toothholder and sleeve. The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.
Specification
Description | Unit | lw500fn | zl50gn | lw500kn |
Rated operating load | kg | 5000 | 5000 | 5000 |
Bucket capacity | m³ | 2.5~4.5 | 2.5~4.5 | 2.7~4.5 |
Machine weight | kg | 16900 | 17500 | 17200 |
Dump clearance at maximum lift | mm | 3150~3560 | 3100~3780 | 3150~3560 |
Reach at maximum lift | mm | 1100~1190 | 1100~1220 | 1100~1190 |
Wheel base | mm | 2960 | 3300 | 3300 |
Tread | mm | 2250 | 2250 | 2250 |
Height of hinge at maximum lift height | mm | 4112 | 4112 | 4112 |
Working height(fully lifted) | mm | 5510 | 5510 | 5407 |
Max.breakout force | kN | 170 | 175 | 170 |
Hydraulic cycle time-raise | s | ≤6 | ≤6S | ≤6.5 s |
Total hydraulic cycle time | s | ≤10.5 | ≤11S | ≤11 s |
Min. turning radius over tyres | mm | 5950 | 5925 | 5925 mm |
Articulation angle | ° | 35 | 38 | 30 º |
Gradeability | ° | 28 | 30 | 45 º |
Tyre size | 23.5-25-16PR | 23.5-25-16PR | 23.5-25-16PR | |
Overall machine dimension L×W×H | mm | 7910×3016×3515 | 8225×3016×3515 | 8870*3000*3350 |
Model | WD10G220E21 | SC110B220G2B1 | WD10G220E21 | |
Rated Power | kW | 162 | 162 | 162 |
Details Images
