Help CenterJoystick Control Zl12f Front Small Wheel Loader
Related Products
-
New Factory Export 3 Ton ZL30 TCM Wheel Loader With CE for SaleNegotiableMOQ: 1 -
GOOD QUALITY!! China Large Construction Mining Use 5 Ton Wheel Loader ZL50/956 Front-end Shovel Loader With CE With Rock BucketNegotiableMOQ: 1
-
China Map 600kg Loading ZL06 906 908 Mini Shovel Loader Front LoaderNegotiableMOQ: 1
-
Mini Wheel Loader ZL16 With Shovel LoaderNegotiableMOQ: 1
-
Low Price China ZL20 White Colour Wheel Shovel Loader With 4 in 1 Bucket and V-blade,compact Front LoaderNegotiableMOQ: 1
ZL12 wheel loader with CE
Light construction machinery COMPACT 1.2 Ton wheel loader
Mini Wheel Loader ZL12F with CE Wheel loader manufactuer
1.2 Ton Wheel loader CE
Wheel loader 1.2 Ton equip with :hydraulic 240 torque converter,3-way pilot control,adjustable steering wheel,quick hitch,luxury seat,new cabin with warm and new engine cover,bigger tire
Weifang Map Power is real factory to produce all kinds of wheel loaders, such as: ZL08 ZL10 ZL12,ZL16, ZL20, ZL30, ZL16 Long-armed Loader, ZL50GI Loader,Big Ore Loader, Coal Loader, Long-armed Loader, High-efficiency Loader.Multi-function Wheel Loader ZL12F/912/ 1.2 Ton can be with Snow Blade, Snow bucket ,Pallet fork , Grapple fork ,4 in 1 Bucket ,Baler,Grader, road sweeping machine,snow blower,light bucket ,auger and etc.
1.2 Ton Wheel loader Light Construction Machine Features
Fully hydraulic steering,power shift hydraulic operated working device.The full hydraulic steering system is smooth in operation, stable and reliable in performance
Optional attachments like pallet fork,grass fork,snow blade and snow buckets available to all materials.
High boom lifting capacity for heavy duty handing jobs.
The bucket is equipped with automatic leveling device, so that the operation is easier.
Big tractive force and traction device at the rear end, which meet more needs.
Technical Data:
Mini loader ZL12F CE Specifications
|
Engine Details |
|
|
Model |
Changchai 490 |
|
Engine type |
In-line arrangement, water-cooled, four-cycle diesel Engine |
|
Rated Power |
33kw |
|
Rated Speed |
2200 r/min |
|
Min.ful consumption |
230 g/kw.h |
|
Bucket |
|
|
Bucket Capacity |
0.65m3 |
|
Bucket type |
Heavy-duty bolt on teeth |
|
Max. Breakout Force |
36 KN |
|
Rated Load |
1200 kg |
|
Operating Weight |
3100 kg |
|
Overall Dimensions |
|
|
Overall Length |
4600 mm |
|
Overall Height |
2700 mm |
|
Overall Width |
1730 mm |
|
Max. discharge height |
2200 mm |
|
Wheel base |
1580 mm |
|
Tread |
1400 mm |
|
Operating Specifications |
|
|
Steering System |
Articulated Frame with hydraulic power steering |
|
Min Turning Radius |
4500 mm |
|
Driving System |
Hydraulic converter |
|
Brake System |
|
|
Service Brake |
Four Wheel Hydraulic spread-shoed brake |
|
Parking Brake |
Hand operated |
|
Tyre |
11.00-16 (Width: 24 cm Diameter: 87 cm) |
For more about our wheel loaders smart loaders micro size loader mini loader small loader
pls send us inquiry now
Wheel loader Cabin inside
WEIFANG MAP POWER Your MINI LOADER LIGHT Contruction Machinery Base.
