Help CenterMap Power 1.2m3 Small Front Wheel Loader Exclusive Distributor Wanted
Related Products
-
Light Construction Machinery 1.2ton ZL12 CE Mini Front Shovel LoaderNegotiableMOQ: 1 -
Construction New 908 800kg Compact Front End Wheel Loader ExporterNegotiableMOQ: 1
-
ZL06F 600kg Quick Hitch Compact Farm Front End LoaderNegotiableMOQ: 1
-
Deutz Engine 3 Ton Loader ZL30 Mini Front Shovel Loader Large Wheel LoaderNegotiableMOQ: 1
-
ZL30 Electric Motor 220v Map Power 3 TON Large Compact Front Wheel Loader PriceNegotiableMOQ: 1
2ton,1.1m3 high quality ZL20F loaders for sale
front end loader snow wheel loader loader exclusive distributor wanted
Company Profile
WeiFang Map Power is well-known constructional & agricultural machinery and implements manufactuer since 2007, and we have our own real factory- which located in “China Machinery Town” – WeiFang city. Our main products as following:
- Wheel Loader Series, rated loading weight from 800kgs to 5T,such as:
Mini Type: D25, ZL06, ZL08, ZL10, ZL12,CS915,ZL16,
Middle-sited Type: ZL20, CS920, ZL30,ZL50, ZL60, ZL70 etc.
2. Farm Tractor Series, power from 20hp to 120hp ,such as: MAP254, MAP300, MAP404, MAP504, MAP704, MAP754,MAP804,MAP954,MAP1004,MAP1204 etc.
3. Site Dupers series, rated loading weight to 1T to 10T, such as: FCY10, FCY15, FCY20, FCY30, FCY50, FCY70,FCY100 etc.
4. Wheel & Crawler-type Excavator Series, such as
Map wc-45, map wc-50, map wc-70, map wc-150
Map NT-18, map NT-18A, map-45, map-85, map wd120c etc.
5.Constructional equipments, farm tools and consumable parts of all kinds.
With the experience in professional manufacturing and international trade, Map Power has successfully expanded our business to about 30 countries including Canada, America, Russia, Australia and west Europe and Mid-Asia etc.
Hope to have a long and good cooperation with you.
loaders for sale
|
Overall Dimension |
||
|
1 |
Length(with bucket on ground) |
5850(mm) |
|
2. |
Width(to outside of wheels) |
2050(mm) |
|
3 |
Height(To the top of the cab) |
2860(mm) |
|
4 |
Wheel base |
2400(mm) |
|
5 |
Tread |
1640(mm) |
|
6 |
Min. ground clearance |
310(mm) |
|
Main Technical Specification |
||
|
1 |
Rated load |
2000(Kg) |
|
2 |
Operating weight |
5800KG |
|
3 |
Rated bucket capacity |
1.2(CBM) |
|
4 |
Bucket type |
Heavy-duty bolt teeth |
|
5 |
Max. breakout force |
51kN |
|
6 |
Max. dump clearance |
2950(mm) |
|
7 |
Min. turning radius |
5251mm |
|
8 |
Driving system |
Hydraulic converter |
|
9 |
Traveling speed(Km/h) |
2 forward and 2 reverse |
|
Diesel engine |
||
|
1 |
Model |
YTO 4108/WeiChai 4105 |
|
2 |
Type |
In-line arrangement. Water cooling |
|
3 |
Rated output |
60(kW)/58KW |
|
4 |
Inter-bore of cylinder/stroke |
105×125mm |
|
5 |
Rated speed |
2400(r/min) |
|
6 |
Max. Torque |
275(N.M) |
|
7 |
Starting type |
Electric |
|
8 |
Min. specific fuel consumption |
235(g/Kw.h) |
|
Transmission System |
||
|
(A)Torque Converter |
||
|
1 |
Model |
YJ280 |
|
2 |
Type |
Fixed-spindle power shift |
|
3 |
Cooling type |
Pressure oil circulating |
|
(B)Transmission case |
||
|
1 |
Model |
MAP |
|
2 |
Type |
Power shift, spur gear constantly in mesh |
|
3 |
Gear shift position |
2 Forward and 2 reverse gears |
|
(C)Axle and Tire |
||
|
1 |
Type of main reducer |
spiral bevel gear, single stage |
|
2 |
Size of tire |
20.5/70-16,16.70-20 for optional |
|
Brake system |
||
|
1 |
Service brake |
Air assisted oil on four wheel |
|
2 |
Parking brake |
Hand operated |
|
Steering System |
||
|
1 |
Type |
Middle articulated frame with hydraulic power steering |
