Product Description
4x4 Chinese cheap mini articulated wheel loader front end loader ZL12 Wheel Loader
Product Description
Model | Changchai 490 |
Type | In-line arrangement. Water cooling |
Rated output | 37 (kW) |
Inter-bore of cylinder/stroke | 95 (mm) |
Rated speed | 2300(r/min) |
Max. Torque | 275(N.M) |
Starting type | Electric |
Min. fuel consumption | 230(g/Kw.h) |
Net weight | 240(kg) |
Rated load | 1200(Kg) |
Operating weight | 3200KG |
Rated bucket capacity | 0.45(CBM) |
Bucket type | Heavy-duty bolt teeth |
Max. breakout force | 36kN |
Max. dump clearance | 2650(mm) |
Min. turning radius | 4500mm |
Driving system | Hydraulic converter |
Type of main reducer | spiral bevel gear, single stage |
Size of tire | 1100-16(12-16.5 for optional) |
Service brake | 4 wheel hydraulic brake |
Parking brake | Hand operated |
Performance and characteristic:
1.Using direct injection diesel engine as power, with easy start up and low oil consumption
2.Using special drive axle, with strong ability to overcome obstacle
3.Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space
4.This machine uses hydraulic operation, with simple structure, convenient operation, good performance and reliable quality
5.Widely applying to the construction of agricultural engineering and small and medium building such as road, coal mine,
brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc
3.Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space
4.This machine uses hydraulic operation, with simple structure, convenient operation, good performance and reliable quality
5.Widely applying to the construction of agricultural engineering and small and medium building such as road, coal mine,
brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc
Details Images
Different attachments avaliable
