China mini wheel Loader ZL50,Real Factory Supplies Directly Wheel Loader Series, Customer Design is Welcome.
Main Descriptions for Mini Wheel Loader Series
- Antirust paint with all color, streamlined appearance, beautiful and elegant, and can attach different tools such as: coal bucket, pipe fork, grass fork, stone bucket… to realize multifunction. Wildly used building site, coal mines, brickyard, stone materials factory, urban construction and so on.
- WeiChai Steyr Engine, OTR Tires, Bigger and stronger chassis.
- Bucket that can be set level automatically, "Z" type turning bucket structure, to realize the enormous shovel digging forces.
- Dual pump meeting hydraulic system can economize on oil 10%,
- Central articulated frame and load sensing hydraulic steering gear, short turning radius and flexible turning, can work in narrow site and has sound off-road performance, good traffic ability and larger traction.
- Cabin made by double-layer1.4mm steel plate with strong steel frames inside.
- A fully enclosed cabin and the seats have the functions of vibration reduction and easy adjustment from 6 directions, offers the driver a comfortable and wide view.
|
Performance |
|
|
Overall dimension(mm) |
8,360 x 2,950 x 3,600 |
|
Rated loading weight(kg) |
5,000kg |
|
Overall weight |
17,000kg |
|
Rated bucket capacity(m3) |
3.0-3.2 |
|
Max. breakout force(kn) |
200 |
|
Max. dump height(mm) |
3160 |
|
Max. dump reach(mm) |
1200 |
|
Engine |
|
|
Engine Model |
WeichaiSteyr |
|
Engine type |
Turbocharger, inline, water cooled, direct injection |
|
Rated Power(kw)/(ps) |
162 |
|
Rated Speed(r/min) |
2200 |
|
Max. torque(N.m) |
920 |
|
Max. torque speed(r/min) |
1200-1400 |
|
Lifting, unloading and descending total time(s) |
11.48 |
|
Displacement |
9.726 |
|
Transmission system |
|
|
Model of torque converter |
YJSW315 |
|
Pattern |
Single stage two phase four components |
|
Transmission type |
Power shift plant structure |
|
Number of gear |
2 forward, 2 reverse |
|
Max. travel speed |
38km/h |
|
Drive axle |
|
|
Main reducer pattern |
Spiral bevel gear first reduction |
|
Pattern of wheel side moderation |
Single stage planetary |
|
Tire |
|
|
Tires |
26.5-25 |
|
Steering system |
|
|
Pattern |
Full hydraulic steering system |
|
Max. turning radius (outside of bucket)(mm) |
7260 |
|
Max. turning angle |
35°±1 |
|
Hydraulic system |
|
|
Implement pump |
P7600-F125 |
|
Displacement(L/min) |
275 |
|
System working pressure(Mpa) |
18 |
|
Distribution device model |
DF32 |
|
Pilot valve model |
DJS |
|
Brake system |
|
|
Service brake |
Air assisted oil disc on four wheel |
|
Parking brake |
Soft control, disc type |
Quality Assurance
- Have established and implemented a standard procedure for quality management system and product certification.
- QA/QC inspectors work independently form the production lines
- Keep its supplier assessment reports and be traced by lot identification to the appropriate raw material test reports
- A procedure to conducting random inspection after final packaging.
- A clear procedure for handling customer feedback. “7 Days Guarantee” for customer renewing the consumable accessories.
- Tool case and partly consumable accessories attached with shipment meanwhile
- After-sales and Quality Warrant Contact for every purchase order.
