DO-BJW600 Portable micro-dissolved oxygen analyzer
Introduction:
DO-BJW600 portable trace dissolved oxygen analyzer
is a high-performance portable measuring
instrument, used to measure the concentration
of oxygen content in aqueous solution, especially
for the detection of low concentration dissolved
oxygen in ultra-pure water.It can be widely used
in many industries such as electric power,
petrochemical, steel and so on.
Features:
1.The polarographic microvolume dissolved oxygen detectionelectrode is suitable for the detection of low concentration
oxygen content with the measurement accuracy of microgram.
2. The instrument adopts integrated structure design, small size,light weight, easy to carry and put.
3. The measuring part adopts the whole waterproof structuredesign, the overall waterproof effect reaches IP65, a variety
of installation and placement, making the measurement more
convenient.
4. High brightness OLED lattice LCD display, can read dataclearly in a certain distance.
5. Automatic USB interface, not only can be charged, but alsocan be connected to the bit machine for reading data.
Technical specifications:
Display: Chinese/English display, 128×64 OLED lattice LCD
Range : (0 ~ 20) g/L, (0 ~ 200) g/L, (0 ~ 20) mg/L(automatic shift)
Discrimination rate: 0.1 g/L;0.01 mg/L;
Maximum display error of instrument: 1.5%FS and 1ug/L (the larger);
Reading response time: 90% of the change within 60 seconds at 25ºC
Temperature compensation range : (0 ~ 50) ºC (manual or automatic)
Temperature measurement accuracy: ±0.5ºC
Resolution of temperature measurement: 0.1ºC response time: ≤60s
Salinity compensation error: ± 2%
Sample conditions: temperature range: 5 ~ 50ºC
Flow range: 100 ~ 350ml/min
Water sample allowed solid ingredients: ≤5 microns (no colloidal material, no grease)
Ambient temperature: 5 ~ 45ºC
Ambient humidity: ≤90%RH (no condensation)
Charging power supply: external charging base,
voltage: AC(198 ~ 242)V, frequency: (49 ~ 51)Hz
Working power supply: dc3.7v rechargeable lithium ion battery (built-in)
Usage time: the working time of a single charge shall be no less than 30h
Storage and transportation temperature :(-20 ~ 55) ºC (excluding electrodes, the electrodes should be higher than 0ºC)
Overall dimensions: 260mm×130mm×140mm (width × height × length)
Weight: 2.5 kg
