Specification
| Diameter range | 80-1600mm |
| Thickness of strip | 0.4-1.3mm Galvanized steel |
| 0.8 mm stainless steel | |
| 0.4-1.2mm Aluminum | |
| Strip Width standard | 137-140mm |
| Production speed Max. | 60m/min, depending on material |
| Cutting system | The patented flying slitter |
| Blanking | Automatic set length, automatic to reverse material, no stopping producing and cutting |
| Motor Poer | 11 kw (BONENG transmission) |
| Electrical apparatus element | Mitsubishi, Schneider |
| Pneumatic component | AIRTAC ,FESTO |
| Cutting blade material | W18Mo4V |
| Run out table Material weigh | 1 T |
| Material volume requirements | |
| N. W. | 2900 kg |
| G.W. | 3200 kg |
T&L Machinery- Spiral Tube Former Pipe Duct Making Machine
Spiral tube former Duct mold with different size
| 1. Standard Service: |
|
Our factory provide the service for the customer forever, if the customer need operation help, can contact us by MSN, Skype, Email and Telephone at any time, we provide 24 hours on-line service. |
| 2. Installation: |
|
Our factory can send our engineer to the customer’s factory install, commission and training freely .The customer provide the double trip tickets, food and accommodation for our engineer. The customer also can send the engineer to our factory to learn the operation and maintains freely. |
| 3. Quality Guarantee: |
|
Our guarantee time is 14 months from B/L Date ,If any component is damaged during guarantee time,we can send the component to the customer By DHL,TNT freely. |
| 4. Order Processing: |
|
