Home > Products > Tube - machines > Hydraulic Pipe and Tube Bending Machine Tiandjin for Tubes and Profiles
Hydraulic Pipe and Tube Bending Machine Tiandjin for Tubes and Profiles
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Automatic Pipe and Metal Steel Square Tube Bending Machines Indian Price Chair Frame
-
89nc Manual High Quality 3d Square Pipe Tube Bending Machine 4 Inch
-
Cnc Square Laser Copper Tube Cutting Bending Machine
-
Cnc Hydraulic Pipe and Tube Bending Machines Tubing Bender
-
Upgraded Manual Hydraulic Round/square Pipe/tube Bending Machine to el Price Stainless Steel
-
Cnc 38cnc 2a 1s . Manual Mandrel Double Head Steel Pipe Bending Machine From Diameter With Push Rollers for Stainless Steel Plat
Product Description
Products Description
OD (Inch) | OD (mm) | WT (mm) | Mandrel Length (mm) | Push bending | Model |
1/3 | 8 | Wire | - | ✓ | WB-8CNC-5A-3D |
2/5 | 10 | Wire | - | ✓ | WB-10CNC-5A-3D |
1/2 | 12 | Wire | - | ✓ | WB-12CNC-5A-3D |
5/9 | 14 | Wire | - | ✓ | WB-14CNC-5A-3D |
5/7 | 18 | 1.5 | 2000 | Option | SB-18CNC |
1 | 25 | 2.0 | 2500 | Option | SB-25NCB SB-25CNC |
1 1/2 | 38 | 3.0 | 3500 | Option | SB-38NCB SB-38CNC |
2 | 50 | 3.0 | 3800 | Option | SB-50NCB SB-50CNC |
2 1/2 | 65 | 4.0 | 4000 | Option | SB-65NCB SB-65CNC |
3 | 75 | 4.0 | 4200 | Option | SB-75NCB SB-75CNC |
3 1/2 | 89 | 4.0 | 4500 | Option | SB-89NCB SB-89CNC |
4 | 100 | 5.0 | 4500 | Option | SB-100NCB SB-100CNC |
4 1/2 | 120 | 6.5 | 6000 | Option | SB-120NCB SB-120CNC |
5 | 130 | 6.5 | 6000 | Option | SB-130NCB SB-130CNC |
6 1/2 | 168 | 10.0 | Custom-made | Option | SB-168NCB SB-168CNC |
7 1/2 | 189 | 10.0 | Custom-made | Option | SB-189NCB SB-189CNC |
8 1/2 | 219 | 20.0 | Custom-made | - | SB-219NCB SB-219CNC |
12 1/2 | 325 | 20.0 | Custom-made | - | SB-325NCB SB-325CNC |
12 1/2 | 325 (Heat Bend) | 20.0 | Custom-made | - | IB-325 |
16 1/2 | 426 (Heat Bend) | 20.0 | Custom-made | - | IB-426 |
Application industry | ||||||
Furniture | Boiler | Exhaust | Shipyard /oil rig | |||
Head rest | Heavy vehicle cabin | Green house | Health care | |||
Aerospace/aviation | Serpentine bending | Fitness | Brake line | |||
3D Auto CNC Steel Tube Bending Machine
1. Tube bending, feeding and rotating by servo motor. There is 11 axis fully auto as option.
2. Stacks: 1, 2, 3, 4, 5, 6 as option.
3. Industry PC controller 15" touch screen, easy operation. Video of operate.
4. Easy to change bend tooling. Video of changing tooling.
Details Images
PAD / Mobile phone / PC monitoring production by camera. Remote function.
Can connect to Internet by WIFI / Net wire / 4G card.
Industry PC controller. Windows system.
Read 3D / DWG drawing by USB port or internet.
Simulate the bending.
Reducer: Taiwan ROLADRIVE, with high torque.
SANCO engineer do remote to solve your problem.
Air conditioning, adjust the temperature of the electrical box.
Transformer, for 220V, 380V, 415V and 440V.
Bend tooling.
Hand wheel: Precise control under manual mode.
For different tube product.
Send your requirement, SANCO give you proposal.
Contact us by email: aran@sancomachine.com
Whatsapp/Wechat: +8618351692880
Whatsapp/Wechat: +8618351692880
Option (Multi-function in one machine) | ||||||
Left and right direction bending | Pushing / Rolling | Robot hand | Auto punching | |||
Auto cutting | Auto welding seam detection | Auto loading | Auto unloading | |||
Infrared safety fence | Production line | Booster | Bend Nylon tube | |||
Contact us
SANCO GROUP (Since 1984)
Cell phone / Wechat / WhatsApp: +8618351692880
Email: aran@sancomachine.com
Company Profile
Industry 4.0
SANCO GROUP is committed to industry 4.0 system R&D and innovation.
Send us your ideas and we will help you realize them.
Service
Service Station | Country | After Sales |
Argentina | ✓ | |
Belarus | ✓ | |
Brazil | ✓ | |
Chile | ✓ | |
Egypt | ✓ | |
India | ✓ | |
Indonesia | ✓ | |
Mexico | ✓ | |
Peru | ✓ | |
Poland | ✓ | |
Russia | ✓ | |
Saudi Arabia | ✓ | |
South Africa | ✓ | |
Spain | ✓ | |
Thailand | ✓ | |
Ukraine | ✓ | |
Uzbekistan | ✓ |
SANCO provides global after-sales site services.
SANCO machines can be connected to the Internet to realize remote control and solve your problems.
Service station: Argentina, Belarus, Brazil, Chile, Egypt, India, Indonesia, Mexico, Peru, Poland, Russia, Saudi Arabia, South Africa, Spain, Thailand, Ukraine, Uzbekistan.
Customer's smile
The smile from customers' . (All the pictures agreed by customers)
Contact SANCO
You send an Inquiry. We reply you with a Smile !
SANCO is committed to your solutions.
(Since 1984)
Cell phone / Wechat / WhatsApp: +8618351692880
Email: aran@sancomachine.com
Contact Us
