Home > Industrial Equipment & Components > Valve > Ball Valve > SNS 4M110-06 Pneumatic Aluminum Alloy Solenoid Valve Pneumatic Control Solenoid Valve
SNS 4M110-06 Pneumatic Aluminum Alloy Solenoid Valve Pneumatic Control Solenoid Valve
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1990
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SNS 4M220-08 Control Solenoid Valve 24v dc Pneumatic Aluminum Alloy Solenoid ValveNegotiableMOQ: 1 -
SNS 4M210-08 Series Affordable IP65 24v dc Pneumatic Aluminum Alloy Solenoid ValveNegotiableMOQ: 1
-
SNS 2WG025-08/DC12V 1/4\" BSP High Temperature Brass Electric Solenoid Valve Normally Closed Water, Air, DieselNegotiableMOQ: 1
-
SNS Medium Pressure Brass Pneumatic Solenoid ValveNegotiableMOQ: 1
-
SNS SEU Series Wholesale Cheap Price Pneumatic Quick Air Exhaust ValveNegotiableMOQ: 1
Banner
CHINA SNS PNEUMATIC
------ Leading supplier of pneumatic components in China -----
Products Description
Model
|
4M110-06
|
||||||||||||
Working Media |
Air |
||||||||||||
Action Mode |
Intermal Pilot Type |
||||||||||||
Postion |
5/2 Port |
||||||||||||
Effectice Section Area |
12.0mm2(Cv=0.67) |
||||||||||||
Port Size |
Inlet=Outlet=G1/8 |
||||||||||||
Lubrication |
No Need |
||||||||||||
Working Pressure |
0.15-0.8MPa |
||||||||||||
Proof Pressure |
1.0MPa |
||||||||||||
Working Temperature |
0~60℃ |
||||||||||||
Voltage Range |
±10% |
||||||||||||
Power Consumption |
AC:2.8VA DC:2.8W |
||||||||||||
Insulation Grade |
F Level |
||||||||||||
Protection Class |
IP65(DIN40050) |
||||||||||||
Material Body |
Aluminum Alloy |
||||||||||||
Material Seal |
NBR |
||||||||||||
Connecting Type |
Plug Type |
||||||||||||
Max.Operating Frequency |
5 Cycle/Sec |
||||||||||||
Min.Excitation Time |
0.05 Sec |
||||||||||||
Certifications
FAQ
Q1. Are you a manufacturer or a trading company?
A1. We are a leading manufacturer of all pneumatic products. Welcome to visit our factory at any time.
Q2. What’s the payment term?
A2. T/T, MasterCard, VISA, E-Checking, Boleto, Pay Later.
Q3. How about the delivery time ?
A3. 1-3 days for normal models. For big orders, it takes about 10-15 days.
Q4. What is the standard of package?
A4. Export standard package or special package according to customers' requirement.
Q5. What kind of product quality does your factory offer?
A5. We are top 3 supplier in Chinese market. We offer top quality to our clients.
Q6. Do you accept OEM business?
A6. We do OEM .
Q7. What market do you already sell to?
A7. We already ship to Asia, Europe, North America, South America, Africa, Oceania.
Q8. What kind of certificate do you have ?
A8. We have ISO9001, CE, CCC, etc.
