Mitsubishi Network Interface Board Q80BD-J71LP21G

Type

Model

Outline

CC-Link IE Control

Network

Q80BD-J71GP21-SX

PCI bus/PCI-X bus, Japanese/English OS compatible, multi-mode fiber optic cable, dual loop,control network (control/normal station)

Q81BD-J71GP21-SX

PCI Express bus, Japanese/English OS compatible, multi-mode fiber optic cable, dual loop,control network (control/normal station)

Q80BD-J71GP21S-SX

PCI bus/PCI-X bus, Japanese/English OS compatible, multi-mode fiber optic cable, dual loop,control network (control/normal station), with external power supply function

Q81BD-J71GP21S-SX

PCI Express bus, Japanese/English OS compatible, multi-mode fiber optic cable, dual loop,control network (control/normal station), with external power supply function

CC-Link IE Field Network

Q81BD-J71GF11-T2

PCI Express compatible, Ethernet connections in line, star, or line and star mixed, configurable as master or local station.

MELSECNET/H(10)

Optical loop(SI)

Q81BD-J71LP21-25

PCI Express bus, Japanese/English OS compatible, SI/QSI/H-PCF/broadband H-PCF fiber optic cable, dual loop,control network (control/normal station)

Q80BD-J71LP21-25

PCI bus, Japanese/English OS compatible, SI/QSI/H-PCF/broadband H-PCF fiber optic cable, dual loop,control network (control/normal station)

Q80BD-J71LP21S-25

PCI bus, Japanese/English OS compatible, SI/QSI/H-PCF/broadband H-PCF fiber optic cable, dual loop,control network (control/normal station), with external power supply function

Optical loop(GI

Q80BD-J71LP21G

PCI bus, Japanese/English OS compatible, GI-50/125 fiber optic cable, dual loop,

control network (control/normal station)

Coaxial bus

Q80BD-J71BR11

PCI bus, Japanese/English OS compatible, 3C-2V/5C-2V coaxial cable, single bus,

control network (control/normal station)

CC-Link

Q81BD-J61BT11

PCI Express bus, Japanese/English OS compatible, master/local interface board, CC-Link Ver. 2 compatible

Q80BD-J61BT11N

PCI bus, Japanese/English OS compatible, master/local interface board, CC-Link Ver. 2 compatible
