EH3 Series Digital-Analog Output Module DELTA PLC DVP08HN11T

EH3 Series Digital / Analog Module
Product Name Output Method Inputs Outputs Model Name
Digital Module Relay 4 4 DVP08HP11R
Transistor 4 4 DVP08HP11T
Relay - 8 DVP08HN11R
Transistor - 8 DVP08HN11T
- 8 - DVP08HM11N
Relay 8 8 DVP16HP11R
Transistor 8 8 DVP16HP11T
- 16 - DVP16HM11N
- 32 - DVP32HM11N
Relay - 32 DVP32HN00R
Transistor - 32 DVP32HN00T
Relay 16 16 DVP32HP00R
Transistor 16 16 DVP32HP00T
Relay 24 24 DVP48HP00R
Transistor 24 24 DVP48HP00T

Analog Module		 • 4 points of analog voltage (-10 V ~ +10 V) / current (-20 mA ~ +20 mA) *1
• Input resolution: 14-bit• Built-in RS-485 interface		 DVP04 AD-H2
• 4 points of analog voltage (0 V ~ +10 V) / current (0 mA ~ +20 mA) output *1
• Resolution: 12-bit• Built-in RS-485 interface		 DVP04DA-H2
• 4 points of analog voltage (-10 V ~ +10 V) / current (-20 mA ~ +20 mA) input
• 2 points of analog voltage (0 V ~ +10 V) / current (0 mA ~ +20 mA) output•Resolution: 12-bit• Built-in RS-485 interface		 DVP06XA-H2
• 4 points of platinum RTD (Pt100, Pt1000, Ni100, Ni1000) sensor input *1 / 0 ~ 300Ω or 0 ~ 3000Ω resistance input• Resolution: 0.1C
• Built-in RS-485 interfac		 DVP04PT-H2
• 4 points of thermocouple (J, K, R, S, T, E, N Type) sensor input *1 / 0 ~ 150mVvoltage inputAnalog Module • Resolution: 0.1C
• Built-in RS-485 interface		 DVP04TC-H2
• 8 points of thermocouple (J, K, R, S, T, E, N Type) sensor input *1 /  0 ~ 150mVof ±150mV voltage input• Resolution: 0.1C
• Built-in RS-485 interface		 DVP08TC-H2
• 4 channels of differential voltage (-10 V ~ +10 V) / current (-20 mA ~ +20 mA)input• Resolution: 16-bit• Built-in RS-485 interface DVP04 AD-H3
• 4 channels of voltage (-10 V ~ +10 V) / current (0 ~ +20 mA) output• Resolution: 16-bit• Built-in RS-485 interface DVP04DA-H3
• 4 channels of differential voltage (-10 V ~ +10 V) /  current (-20 mA ~ +20 mA) input• 2 channels of voltage (-10 V ~ +10 V) / current (0 ~ +20 mA) output• Resolution: 16-bit• Built-in RS-485 interface DVP06XA-H3
*1. Digital / analog photocoupler isolation. No isolation among channels
